WAGO 769112022000 12-pole female connector
The WAGO 769-112/022-000 is a pluggable, 12-pole female connector designed for reliable conductor connections in industrial environments. It adheres to EN 61984 standards, ensuring safe operation. The connector utilizes WAGO’s CAGE CLAMP® connection technology for secure and easy connections, accommodating conductors from 0.08 to 4 mm². Its robust polyamide (PA66) insulation and V0 flammability rating provide excellent protection and safety. This connector is ideal for applications requiring multiple connections with high voltage and current capacity.
WAGO 769112022000 12-pole female connector Specifications:
- Nominal voltage (III/3): 500 V
- Rated surge voltage (III/3): 6 kV
- Rated current: 32 A
- Connection technology: CAGE CLAMP®
- Actuation type: Operating tool
- Connectable conductor materials: Copper
- Nominal cross-section: 4 mm²
- Solid conductor: 0.08 … 4 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 4 mm² / 28 … 12 AWG
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- Pole No.: 12
- Total number of connection points: 12
- Total number of potentials: 12
- Wiring type: Front-entry wiring
- Width: 60 mm / 2.362 inch
- Height: 37.1 mm / 1.461 inch
- Depth: 26.5 mm / 1.043 inch
- Module width: 5 mm / 0.197 inch
- Color: gray
- Insulation material: Polyamide (PA66)
- Flammability class per UL94: V0
- Fire load: 0.527 MJ
- Weight: 29.7 g
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918547734
- Customs tariff number: 85366990990
