WAGO 232104026000 4 Pole Angled Connector
The WAGO 232-104/026-000 is a 4-pole angled female plug within WAGO's Multi Conn. System. It's designed for efficient and secure connections in industrial environments. Key features include coding fingers to prevent incorrect insertion, integrated fixing flanges for secure mounting, and a cage clamp connection for easy termination of conductors ranging from 0.08 mm² to 2.5 mm² (28-12 AWG). This connector supports voltage ratings up to 250V and current intensities up to 14A, making it suitable for a wide range of applications. It is also characterized by its compact dimensions (23.9mm height, 22.4mm width, and 22.75mm depth) and a grey color finish.
WAGO 232104026000 4 Pole Angled Connector Specifications:
- Product Group: Multi Conn. System
- Pin Spacing From: 5 mm
- Pin Spacing From (in): 0.197 in
- Pole Count: 4
- Cross Section From (mm²): 0.08 mm²
- Cross Section To (mm²): 2.5 mm²
- Cross Section From (AWG): 28 AWG
- Cross Section To (AWG): 12 AWG
- Connection Method: CAGE CLAMP®CONNECTION
- Measured Voltage EN: 250 V
- Measured Shock Voltage: 4 kV
- Pollution Degree: 3
- Current Intensity EN: 14 A
- Weight: 7.556 g
- Color: grey
- No. of Connection Points: 4
- No. of Potentials: 4
- Height: 23.9 mm
- Height (in): 0.941 in
- Width: 22.4 mm
- Width (in): 0.882 in
- Depth: 22.75 mm
- Depth (in): 0.896 in
- Strip Length From: 8 mm
- Strip Length To: 9 mm
- Strip Length (in): 0.33 in
- Admission Office: ABS, BV, CCA, CSA, DEMKO, GL, KEMA, KR, LR, NEMKO, RMR, UR
- Approval No.: 04-HG469925-PDA, 11915/A0, 5764, 154112-1466354, 88126, 17296-00HH, 2083746.02, HMB05880-EL003, 96/20035, P94101840, 11130002, E45171, E45172
- Voltage (V): 250, 400
- Current (A): 12, 14, 15, 16
- Cross Section (mm²): 0.8, 2.5
