WAGO 231104026000 4 Pole Female Plug Connector
The WAGO 231-104/026-000 is a robust 4-pole female plug connector ideal for various industrial applications requiring secure and reliable power transmission. Its cage clamp connection provides a vibration-resistant connection, while the integrated fixing flanges ensure stability in demanding environments. The connector's coding fingers prevent incorrect mating, enhancing system safety and reliability. It is suitable for use in control cabinets, machinery, and other industrial equipment where a compact and dependable connection is essential.
WAGO 231104026000 4 Pole Female Plug Connector Specifications:
- Product Description: FEMALE PLUG; 4 POLE; PIN SPACING 5 MM / 0.197 IN; WITH CODIG FINGERS; WITH INTEGRATED FIXING FLANGES; CAGE CLAMP®CONNECTION
- Packing Unit: 100 pieces
- Product Group: 3 (Multi Conn. System)
- Pin Spacing: 5 mm / 0.197 in
- Pole Count: 4
- Cross Section Range (mm²): 0.08 - 2.5
- Cross Section Range (AWG): 28 - 12 AWG
- Connection Method: CAGE CLAMP®CONNECTION
- Measured Voltage (EN): 250 V
- Measured Shock Voltage: 4 kV
- Pollution Degree: 3
- Current Intensity (EN): 16 A
- Weight: 7.319 g
- Color: grey
- No. of Connection Points: 4
- No. of Potentials: 4
- Height: 14.3 mm / 0.563 in
- Width: 21.5 mm / 0.846 in
- Depth: 26.45 mm / 1.041 in
- Strip Length: 8 - 9 mm / 0.33 in
- Approval Office (ABS): 04-HG469925-PDA
- Approval Voltage (ABS): 400 V
- Approval Current (ABS): 16 A
- Approval Cross Section (ABS): 5.0 mm²
- Approval Office (BV): 11915/A0
- Approval Voltage (BV): 400 V
- Approval Current (BV): 16 A
- Approval Cross Section (BV): 2.5 mm²
- Approval Office (CCA): 5764
- Approval Voltage (CCA): 250 V
- Approval Current (CCA): 16 A
- Approval Cross Section (CCA): 0.08-2.5 mm²
- Approval Office (CSA): 154112-1466354
- Approval Voltage (CSA): 300 V
- Approval Current (CSA): 15 A
- Approval Cross Section (CSA): 22-12 AWG
- Approval Office (DEMKO): 88126
- Approval Voltage (DEMKO): 250 V
- Approval Current (DEMKO): 16 A
- Approval Cross Section (DEMKO): 2.5 mm²
- Approval Office (GL): 17296-00HH
- Approval Voltage (GL): 400 V
- Approval Current (GL): 16 A
- Approval Cross Section (GL): 5.0 mm²
- Approval Office (KEMA): 2083746.02
- Approval Voltage (KEMA): 250 V
- Approval Current (KEMA): 16 A
- Approval Cross Section (KEMA): 0.08-2.5 mm²
- Approval Office (KR): HMB05880-EL003
- Approval Voltage (KR): 250/400 V
- Approval Current (KR): 12/16 A
- Approval Cross Section (KR): 2.5 mm²
- Approval Office (LR): 96/20035
- Approval Voltage (LR): 400 V
- Approval Current (LR): 16 A
- Approval Cross Section (LR): 5.0 mm²
- Approval Office (RMR): 11130002
- Approval Voltage (RMR): 400 V
- Approval Current (RMR): 16 A
- Approval Cross Section (RMR): 5.0 mm²
- Approval Office (UR): E45171
- Approval Voltage (UR): 600 V
- Approval Current (UR): 15 A
- Approval Cross Section (UR): 12 AWG
- Approval Office (UR2): E45172
- Approval Voltage (UR2): 300 V
- Approval Current (UR2): 15 A
- Approval Cross Section (UR2): 22-12 AWG
