WAGO 282422 2-conductor Through Terminal Block
The WAGO 282-422 is a 2-conductor through terminal block designed for use in electrical distribution systems and control panels. It features the innovative CAGE CLAMP® connection technology, which provides a spring-pressure contact that ensures a secure and reliable connection for conductors. The terminal block is suitable for both solid and stranded conductors, accommodating a wide range of wire gauges. Its compact design allows for efficient space utilization on DIN rails, making it ideal for applications where space is limited. The center marking simplifies identification and wiring, contributing to ease of installation and maintenance. The polyamide 66 (PA 66) insulating material provides excellent electrical insulation and durability, ensuring long-term performance in demanding environments.
WAGO 282422 2-conductor Through Terminal Block Specifications:
- rated_voltage_iii_3: 800 V
- rated_impulse_voltage_iii_3: 8 kV
- rated_current: 41 A
- connection_technology: CAGE CLAMP®
- actuation_type: Operating tool
- connectable_conductor_materials: Copper
- solid_conductor_size: 0.2 … 6 mm² / 24 … 10 AWG
- fine_stranded_conductor_size: 0.2 … 6 mm² / 24 … 10 AWG
- strip_length: 12 … 13 mm / 0.47 … 0.51 inch
- total_number_of_connection_points: 2
- total_number_of_potentials: 1
- number_of_levels: 1
- type_of_wiring: Front-entry wiring
- width: 8 mm / 0.315 inch
- height_from_upper_edge_of_din_rail: 32.5 mm / 1.28 inch
- depth: 74.5 mm / 2.933 inch
- design: horizontal
- type_of_mounting: DIN-35 rail
- marking_level: Center marking
- insulating_material: Polyamide 66 (PA 66)
- fire_load: 0.267 MJ
- weight: 15.8 g
- packaging_type: BOX
- country_of_origin: DE
- gtin: 4044918445801
- customs_tariff_no: 85369010000
