WAGO 282601 2-Conductor Terminal Block
The WAGO 282-601 is a versatile 2-conductor through terminal block ideal for DIN rail mounting in industrial control panels and machinery. Its robust cage clamp connection ensures reliable termination of conductors, while the front-entry design simplifies wiring. The terminal block is rated for high voltage and current, making it suitable for demanding applications. It is also marked laterally for easy identification and offers a compact design to optimize space utilization. Various approvals are listed, demonstrating its compliance with international standards.
WAGO 282601 2-Conductor Terminal Block Specifications:
- product_group: Rail Mounted Terminal Blocks
- cross_section_from_mm2: 0,2
- cross_section_to_mm2: 6
- cross_section_from_awg: 24
- cross_section_to_awg: 10
- connection_method: CAGE CLAMP®CONNECTION
- measured_voltage_en: 800
- measured_shock_voltage: 8
- pollution_degree: 3
- current_intensity_en: 41
- weight: 13,26
- color: grey
- wiring_type: Front-entry
- no_of_connection_points: 2
- no_of_potentials: 1
- height: 31,5
- height_in: 1,24
- width: 8
- width_in: 0,315
- depth: 62
- depth_in: 2,44
- strip_length_from: 12
- strip_length_to: 13
- strip_length_in: 0,49
- admission_office: ABS, BBJ, BV, CCA, CSA, DEMKO, Dep.MaE, DNV, GL, KEMA, KR, LR, PRS, RMR, SABS, SABS-EX, UL, UR
- approval_no: 05-HG476175/1-PDA, B/12/700/03, 07436/Co, NL5448, 154112-1505033, 78012, CS4867N, E7570, 17295-00HH, 2036066.01, HMB05880-EL001, 91/20112(E5), TE/1718/880590/08, 11130002, 751/82640, e741/85712/W491, E45172, E45172
Buy the 282-601 WAGO 2-Conductor Terminal Block | myMectronic
Purchase the genuine WAGO 282-601 terminal block securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy WAGO 282601?
You can click on the BUY or RFQ button to purchase 282601 from an authorized WAGO distributor.
How do I troubleshoot issues or seek technical support for part 282601?
You can download the 282601 datasheet or visit the WAGO website for support.
Who is the manufacturer of 282601?
WAGO
