WAGO 283901 2-Conductor Through Terminal Block
The WAGO 283-901 is a versatile 2-conductor through terminal block suitable for a wide range of industrial applications, including power distribution, control circuits, and automation systems. Its DIN rail mounting capability allows for easy integration into existing electrical panels. The block is designed to handle wire cross-sections from 0.2 to 16 mm² (24-06 AWG) and offers a robust connection for wires up to 800V and 76A. The center marking simplifies wiring and ensures accurate connections, while the grey color provides a consistent aesthetic.
WAGO 283901 2-Conductor Through Terminal Block Specifications:
- Cross section1: 0.2 - 16 mm²
- Cross section2: 24 - 06 AWG
- Strip length: 16 - 17 mm
- Measured voltage: 800 V
- Measured shock voltage: 8 kV
- Pollution degree: 3
- Current intensity: 76 A
- Height: 37.5 mm
- Width: 12 mm
- Depth: 94.5 mm
- No. of connection Points: 2
- No. of potentials: 1
- COLOR: grau
- WEIGHT: 35.815 g
