WAGO 7131105 10-pole Female Connector
The WAGO 713-1105 is a versatile 10-pole female connector ideal for wire-to-board connections in confined spaces. Its unique, compact, double-row design accommodates conductor cross-sections up to 1.5 mm², offering a secure and reliable connection for various conductor types. The integrated coding fingers ensure protection against mismating, while the centered strain relief plate anchors conductors and provides easy access for wiring. This connector is suitable for a wide range of industrial applications requiring robust and space-saving connectivity solutions.
WAGO 7131105 10-pole Female Connector Specifications:
- Rated Voltage (III/3): 80 V
- Rated Surge Voltage (III/3): 2.5 kV
- Rated Voltage (III/2): 160 V
- Rated Surge Voltage (III/2): 2.5 kV
- Nominal Voltage (II/2): 250 V
- Rated Surge Voltage (II/2): 2.5 kV
- Rated Current: 10 A
- Rated Voltage UL (Use Group B): 300 V
- Rated Current UL (Use Group B): 10 A
- Rated Voltage UL (Use Group C): 50 V
- Rated Current UL (Use Group C): 10 A
- Rated Voltage CSA (Use Group B): 300 V
- Rated Current CSA (Use Group B): 10 A
- Connection Technology: CAGE CLAMP®
- Solid Conductor: 0.08 … 1.5 mm² / 28 … 16 AWG
- Fine-Stranded Conductor: 0.08 … 1.5 mm² / 28 … 16 AWG
- Fine-Stranded Conductor with Insulated Ferrule: 0.25 … 1 mm²
- Fine-Stranded Conductor with Uninsulated Ferrule: 0.25 … 1 mm²
- Strip Length: 6 … 7 mm / 0.24 … 0.28 inch
- Pole No.: 10
- Total Number of Connection Points: 10
- Total Number of Potentials: 10
- Number of Connection Types: 1
- Number of Levels: 2
- Conductor Entry Direction to Mating Direction: 0 °
- Pin Spacing: 3.5 mm / 0.138 inch
- Width: 19 mm / 0.748 inch
- Height: 18.8 mm / 0.74 inch
- Depth: 16 mm / 0.63 inch
- Contact Type: Female connector/socket
- Mismating Protection: Yes
- Locking of Plug-in Connection: Without
- Insulation Material: Glass fiber-reinforced polyamide (PA66 GF)
- Flammability Class per UL94: V0
- Clamping Spring Material: Chrome nickel spring steel (CrNi)
- Contact Material: Copper alloy
- Contact Plating: tin-plated
- Fire Load: 0.082 MJ
- Weight: 5.3 g
- Limit Temperature Range: -60 … +100 °C
- Product Group: 3 (Multi Conn. System)
- Packaging Type: BOX
- Country of Origin: PL
- GTIN: 4045454696085
- Customs Tariff Number: 85366990990
