WAGO 7131108 16-pole Female Connector
The WAGO 713-1108 is a 16-pole female connector within the MCS – MULTI CONNECTION SYSTEM. It's designed for universal conductor types and offers a compact, double-row configuration ideal for high-density wire-to-board connections in confined spaces. The connector incorporates a centered strain relief plate that acts as both a connection/disconnection handle and provides easy access to operating slots. Its 100% mismating protection ensures reliable connections, and the CAGE CLAMP® connection technology provides secure and easy termination. Suitable for a wide range of industrial applications requiring robust and space-saving conductor connections.
WAGO 7131108 16-pole Female Connector Specifications:
- conductor_size: 0.08 … 1.5 mm² / 28 … 16 AWG
- fine_stranded_conductor: 0.08 … 1.5 mm² / 28 … 16 AWG
- ferruled_conductor: 0.25 … 1 mm²
- strip_length: 6 … 7 mm / 0.24 … 0.28 inch
- pole_number: 16
- connection_points: 16
- potentials: 16
- pin_spacing: 3.5 mm / 0.138 inch
- width: 29.5 mm / 1.161 inch
- height: 18.8 mm / 0.74 inch
- depth: 16 mm / 0.63 inch
- rated_voltage_iii3: 80 V
- rated_surge_voltage_iii3: 2.5 kV
- rated_voltage_iii2: 160 V
- rated_surge_voltage_iii2: 2.5 kV
- rated_voltage_ii2: 250 V
- rated_surge_voltage_ii2: 2.5 kV
- rated_current: 10 A
- material: Glass fiber-reinforced polyamide (PA66 GF)
- flammability_class: V0
- weight: 8.2 g
- operating_temperature: -60 … +100 °C
- product_group: 3 (Multi Conn. System)
- packaging: BOX
- origin: PL
- gtin: 4045454667351
- customs_tariff_number: 85366990990
- UL_voltage_group_B: 300 V
- UL_current_group_B: 10 A
- UL_voltage_group_C: 50 V
- UL_current_group_C: 10 A
- CSA_voltage_group_B: 300 V
- CSA_current_group_B: 10 A
- connection_technology: CAGE CLAMP®
- actuation_type: Operating tool
- mismating_protection: Yes
- contact_type: Female connector/socket
- contact_material: Copper alloy
- contact_plating: tin-plated
