WAGO 7871701 Power Supply
The ECO switched-mode power supply provides a reliable 12 VDC output at 2 A, suitable for control cabinet applications. Encapsulated for durability, it features natural convection cooling and can be mounted in various positions on DIN rails. It offers SELV and PELV isolation for safety, with an efficiency of 80% and an external fuse requirement for the DC input. The unit includes indicator LEDs for operation status and supports parallel operation, making it ideal for industrial automation and control systems requiring stable power and high reliability.
WAGO 7871701 Power Supply Specifications:
- Nominal output voltage: DC 12 V (SELV)
- Output voltage range: DC 10...14 V (adjustable)
- Nominal output current: 2 A (12 VDC; 110...240 VAC)
- Nominal power: 24 W
- Efficiency: 80% (230 VAC; 2 A)
- Input voltage: AC 90...264 V, DC 125...375 V
- Inrush current: <18A
- Power factor correction: Passive
- Mains failure hold-up time: 210 ms (230 VAC)
- Protection class: IP20
- Isolation voltage: PRI-SEC 4.242kV, PRI-GND 2.2kV, SEC-GND 0.7kV
- Overvoltage category: II
- Overload behavior: Constant power, shutdown & auto-restart
- LED indicator: Green DC OK
- Operating temperature: -20...60°C
- Storage temperature: -25...75°C
- Humidity: 10...95% (no condensation)
- Standards: EN 61204-3, EN 60335-1, EN 61558-2-6, EN 62368-1
- Protection features: Short circuit, no-load proof, transient protection
- Mounting: DIN-35 rail, screw mount
- Dimensions: Width 30mm, Height 90mm, Length 99mm
- Housing material: Encapsulated plastic
- Weight: 250g
Buy the WAGO Series Eco Power Supply: 7871701
Purchase the WAGO 7871701 Eco power supply online for reliable 12VDC output at 2A, perfect for control cabinets and industrial automation. Its encapsulated design ensures durability, and the DIN rail mounting allows flexible installation. The unit features LED indicators for operational status, high efficiency of 80%, and safety features including SELV/PELV isolation and overcurrent protection. Ideal for automation systems needing stable power, easy installation, and long-term performance, this power supply is your trusted choice for industrial applications.
Get WAGO 7871701 today—built for precision and long-lasting durability in industrial power solutions.
Frequently Asked Questions
Where can I buy WAGO 7871701?
You can click on the BUY or RFQ button to purchase 7871701 from an authorized WAGO distributor.
How do I troubleshoot issues or seek technical support for part 7871701?
You can download the 7871701 datasheet or visit the WAGO website for support.
Who is the manufacturer of 7871701?
WAGO
