WAGO 721606 6-pole Male Connector
The WAGO 721-606 is a robust 6-pole male connector designed for versatile applications in industrial settings. Its key feature is the 100% protection against mismating, ensuring reliable connections. The connector utilizes WAGO's CAGE CLAMP actuation for easy cable pre-assembly and on-unit wiring, accommodating various conductor types. It's ideal for wire-to-wire and board-to-wire connections and can be mounted on panels or through panels with optional snap-in feet or flanges. The connector is designed to meet stringent safety standards and offers excellent electrical performance.
WAGO 721606 6-pole Male Connector Specifications:
- connector_type: Male connector/plug
- mismating_protection: Yes
- conductor_types: Universal
- actuation_type: Operating tool
- solid_conductor_size: 0.08 … 2.5 mm² / 28 … 12 AWG
- fine_stranded_conductor_size: 0.08 … 2.5 mm² / 28 … 12 AWG
- ferruled_fine_stranded_conductor_size: 0.25 … 1.5 mm²
- unferruled_fine_stranded_conductor_size: 0.25 … 2.5 mm²
- strip_length: 8 … 9 mm / 0.31 … 0.35 inch
- pole_number: 6
- total_connection_points: 6
- total_potentials: 6
- connection_levels: 1
- conductor_entry_direction: 0 °
- pin_spacing: 5 mm / 0.197 inch
- width: 33.2 mm / 1.307 inch
- height: 14.3 mm / 0.563 inch
- depth: 27.5 mm / 1.083 inch
- nominal_voltage_iii3: 320 V
- rated_surge_voltage_iii3: 4 kV
- nominal_voltage_iii2: 320 V
- rated_surge_voltage_iii2: 4 kV
- nominal_voltage_ii2: 630 V
- rated_surge_voltage_ii2: 4 kV
- rated_current: 12 A
- rated_voltage_ul_use_b: 300 V
- rated_current_ul_use_b: 15 A
- rated_voltage_ul_use_d: 300 V
- rated_current_ul_use_d: 10 A
- rated_voltage_ul_1977: 600 V
- rated_current_ul_1977: 15 A
- rated_voltage_csa_use_b: 300 V
- rated_current_csa_use_b: 15 A
- rated_voltage_csa_use_d: 300 V
- rated_current_csa_use_d: 10 A
- insulation_material: Polyamide (PA66)
- flammability_class_ul94: V0
- clamping_spring_material: Chrome nickel spring steel (CrNi)
- contact_material: Electrolytic copper (E Cu)
- contact_plating: tin-plated
- fire_load: 0.168 MJ
- weight: 9.3 g
- operating_temperature_range: -60 … +100 °C
