WAGO 733363 3-pole THT Header
The WAGO 733-363 is a 3-pole THT (Through-Hole Technology) male header designed for robust PCB connections. Its angled solder pins facilitate easy integration into printed circuit boards, while the 100% mismating protection ensures secure and reliable connections. This header is suitable for a wide range of industrial applications where secure and reliable power and signal transmission is required. It is compatible with various CAD/CAE software and offers comprehensive documentation and CAD data for seamless integration into design workflows. The header is also designed with safety in mind, adhering to relevant standards and regulations.
WAGO 733363 3-pole THT Header Specifications:
- Rated Voltage (III / 3): 80 V
- Rated Impulse Voltage (III / 3): 2.5 kV
- Rated Voltage (III / 2): 160 V
- Rated Impulse Voltage (III / 2): 2.5 kV
- Rated Voltage (II / 2): 320 V
- Rated Impulse Voltage (II / 2): 2.5 kV
- Rated Current: 6 A
- Rated Voltage UL (Use Group B): 150 V
- Rated Current UL (Use Group B): 4 A
- Rated Voltage CSA (Use Group B): 150 V
- Rated Current CSA (Use Group B): 4 A
- Number of Poles: 3
- Total Number of Potentials: 3
- Pin Spacing: 2.5 mm
- Width: 10 mm
- Height: 11.5 mm
- Height from Surface: 7.8 mm
- Depth: 8.9 mm
- Solder Pin Length: 3.7 mm
- Solder Pin Dimensions: 0.8 x 0.8 mm
- Drilled Hole Diameter: 1.1 mm
- Contact Type: Male Connector/Plug
- Mating Direction to PCB: 0 °
- Material Group: I
- Insulating Material: Polyamide 66 (PA 66)
- Flammability Class UL94: V0
- Contact Material: Electrolytic Copper (E) Cu
- Contact Plating: Tin-plated
- Fire Load: 0.009 MJ
- Weight: 0.5 g
- Limit Temperature Range: -60 … +100 °C
- GTIN: 4044918974349
- Customs Tariff No.: 85366990990
Buy the 733-363 WAGO 3-pole THT Header | myMectronic
Purchase the WAGO 733-363 securely online for reliable PCB connections.
Buy Now
