WAGO 231316037000 16-pole Female Plug Connector
The WAGO 231-316/037-000 is a versatile 16-pole female plug connector within the MCS – MULTI CONNECTION SYSTEM. It offers universal compatibility for all conductor types and simplifies wiring with vertical and horizontal CAGE CLAMP actuation. Integrated test ports enable easy testing, and coding fingers provide secure connections. This connector is suitable for various industrial applications requiring reliable and efficient power distribution and signal transmission.
WAGO 231316037000 16-pole Female Plug Connector Specifications:
- Color: orange
- Nominal Voltage (III/3): 320 V
- Rated Surge Voltage (III/3): 4 kV
- Rated Voltage (III/2): 320 V
- Rated Surge Voltage (III/2): 4 kV
- Rated Voltage (II/2): 630 V
- Rated Surge Voltage (II/2): 4 kV
- Rated Current: 16 A
- Rated Voltage UL (Use Group B): 300 V
- Rated Current UL (Use Group B): 15 A
- Rated Voltage UL (Use Group D): 300 V
- Rated Current UL (Use Group D): 10 A
- Rated Voltage UL (1977): 600 V
- Rated Current UL (1977): 15 A
- Rated Voltage CSA (Use Group B): 300 V
- Rated Current CSA (Use Group B): 15 A
- Rated Voltage CSA (Use Group D): 300 V
- Rated Current CSA (Use Group D): 10 A
- Connection Technology: CAGE CLAMP®
- Solid Conductor Size: 0,08 … 2,5 mm² / 28 … 12 AWG
- Fine-Stranded Conductor Size: 0,08 … 2,5 mm² / 28 … 12 AWG
- Fine-Stranded Conductor w/ Insulated Ferrule: 0,25 … 1,5 mm²
- Fine-Stranded Conductor w/ Uninsulated Ferrule: 0,25 … 2,5 mm²
- Strip Length: 8 … 9 mm / 0.31 … 0.35 inch
- Pole Number: 16
- Total Connection Points: 16
- Total Potentials: 16
- Pin Spacing: 5,08 mm / 0.2 inch
- Width: 97,88 mm / 3.854 inch
- Height: 14,3 mm / 0.563 inch
- Depth: 29,6 mm / 1.165 inch
- Contact Type: Female connector/socket
- Locking: Locking lever
- Material Group: I
- Insulation Material: Polyamide 66 (PA 66)
- Flammability Class: V0
- Clamping Spring Material: Chrome nickel spring steel (CrNi)
- Contact Material: Copper alloy
- Contact Plating: tin-plated
- Fire Load: 0.451 MJ
- Weight: 30.6 g
- Limit Temperature Range: -60 … +85 °C
- Packaging Type: BOX
- Country of Origin: DE
- GTIN: 4044918349468
- Customs Tariff Number: 85366990990
