WAGO 734104 4 Pole Connector
The WAGO 734-104 is a robust 4-pole female connector designed for reliable electrical connections in industrial environments. It features a 3.5mm pin spacing and incorporates coding fingers to ensure correct mating and prevent errors. The connector's CAGE CLAMP® connection technology provides a secure and vibration-resistant termination for solid or stranded wires ranging from 0.08 to 1.5 mm² (28-14 AWG). It is suitable for applications requiring high current carrying capacity (up to 10A) and is approved by various agencies including ABS, BV, CSA, and UR. This connector is ideal for use in control cabinets, machinery, and other industrial equipment where reliable power distribution is essential.
WAGO 734104 4 Pole Connector Specifications:
- Product Description: FEMALE CONNECTOR 4 POLE PIN SPACING 3.5 MM / 0.138 IN
- Product Group: 3 (Multi Conn. System)
- Weight: 3.229 g
- Color: light gray
- No. of Connection Points: 4
- No. of Potentials: 4
- Pole Count: 4
- Height: 13.4 mm
- Height (Imperial): 0.528 in
- Width: 16.2 mm
- Width (Imperial): 0.638 in
- Depth: 18.6 mm
- Depth (Imperial): 0.732 in
- Pin Spacing: 3.5 mm
- Pin Spacing (Imperial): 0.138 in
- Pollution Degree: 2
- Measured Voltage EN: 160 V
- Measured Shock Voltage: 2.5 kV
- Current Intensity EN: 10 A
- Connection Method: CAGE CLAMP® CONNECTION
- Cross Section (mm²): 0.25 - 1.5 mm²
- Cross Section (AWG): 28 - 14 AWG
- Strip Length from: 6 mm
- Strip Length to: 7 mm
- Material Group: xxx-xxx/032-000
- Approval ABS: 04-HG469925/1-PDA
- Approval BV: 11915/A0
- Approval CCA: NL5641
- Approval CSA: 154112-1465035
- Approval DNV: E-9218
- Approval GL: 17296-00HH
- Approval KEMA: 2077592.02
- Approval LR: 96/20035
- Approval RMR: 11130002
- Approval UR: E45171
- Approval UR2: E45172
- Voltage [V]: 250
- Current [A]: 10
- Cross Section [mm²]: 0.5-1.5
