WAGO 734203 2-Conductor Female Plug
The WAGO 734-203 2-conductor female plug is a versatile component within WAGO’s Multi Connection System (MCS). Designed for universal conductor compatibility, it simplifies wiring processes with its innovative CAGE CLAMP actuation, allowing for both vertical and horizontal connection. The plug offers easy cable pre-assembly and on-unit wiring, along with strain relief options for field assembly. Its 100% mismating protection and coding capabilities ensure secure and reliable connections. Suitable for a wide range of industrial applications, the 734-203 contributes to efficient and safe power distribution systems. It is rated for 160V and 10A, and is UL, CSA, and other internationally recognized approvals.
WAGO 734203 2-Conductor Female Plug Specifications:
- Rated voltage (III / 3): 160 V
- Rated impulse voltage (III / 3): 2.5 kV
- Rated voltage (III / 2): 160 V
- Rated impulse voltage (III / 2): 2.5 kV
- Rated voltage (II / 2): 320 V
- Rated impulse voltage (II / 2): 2.5 kV
- Rated current: 10 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 10 A
- Rated voltage UL (Use Group D): 300 V
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 10 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Actuation type: Operating tool
- Solid conductor: 0.08 … 1.5 mm² / 28 … 14 AWG
- Fine-stranded conductor: 0.08 … 1.5 mm² / 28 … 14 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 1.5 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 1.5 mm²
- Strip length: 6 … 7 mm / 0.24 … 0.28 inch
- Pin spacing: 3.81 mm / 0.15 inch
- Width: 9.82 mm / 0.387 inch
- Height: 13.4 mm / 0.528 inch
- Depth: 18.6 mm / 0.732 inch
- Contact type (pluggable connector): Female connector/socket
- Mismating protection: Yes
- Color: orange
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Copper alloy
- Contact plating: tin-plated
- Fire load: 0.034 MJ
- Weight: 1.838 g
- Limit temperature range: -60 … +100 °C
- Number of poles: 2
- Total number of connection points: 2
- Total number of potentials: 2
