WAGO 739203 3-pole PCB Terminal Block
The WAGO 739-203 is a 3-pole PCB terminal block designed for efficient and reliable connections in printed circuit boards. Utilizing the innovative CAGE CLAMP® connection, this terminal block provides a secure and tool-friendly connection process. Its vertical conductor entry allows for space-saving integration into your designs. Rated for 24A and 500V, it's suitable for a wide range of industrial applications including power supplies, automation systems, and control panels. The block is manufactured with high-quality materials, ensuring durability and long-term performance. It is also RoHS compliant, meeting environmental standards.
WAGO 739203 3-pole PCB Terminal Block Specifications:
- Rated Voltage (III/3): 500 V
- Rated Surge Voltage (III/3): 6 kV
- Rated Voltage (III/2): 630 V
- Rated Surge Voltage (III/2): 6 kV
- Rated Voltage (II/2): 1000 V
- Rated Surge Voltage (II/2): 6 kV
- Rated Current: 24 A
- Rated Voltage UL (Use Group B): 300 V
- Rated Current UL (Use Group B): 20 A
- Rated Voltage UL (Use Group D): 300 V
- Rated Current UL (Use Group D): 10 A
- Rated Voltage CSA (Use Group B): 300 V
- Rated Current CSA (Use Group B): 8 A
- Rated Voltage CSA (Use Group D): 300 V
- Rated Current CSA (Use Group D): 8 A
- Connection Technology: CAGE CLAMP®
- Solid Conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-Stranded Conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-Stranded Conductor with Insulated Ferrule: 0.25 … 1.5 mm²
- Fine-Stranded Conductor with Uninsulated Ferrule: 0.25 … 2.5 mm²
- Strip Length: 8 … 9 mm / 0.31 … 0.35 inch
- Pin Spacing: 7.5 mm / 0.295 inch
- Width: 21.5 mm / 0.846 inch
- Height: 19 mm / 0.748 inch
- Height from Surface: 15.8 mm / 0.622 inch
- Depth: 14.3 mm / 0.563 inch
- Solder Pin Length: 3.2 mm
- Solder Pin Dimensions: 0.8 x 1.2 mm
- Drilled Hole Diameter: 1.6 (+0.1) mm
- Material (Insulation): Polyamide (PA66)
- Flammability Class: V0
- Fire Load: 0.079 MJ
- Weight: 4.2 g
- Limit Temperature Range: -60 … +105 °C
