WAGO 7453202 2-pole PCB Terminal Block
The WAGO 745-3202 is a 2-pole PCB terminal block designed for reliable power transmission in various industrial applications. Utilizing WAGO’s innovative CAGE CLAMP® connection technology, this terminal block ensures secure and vibration-resistant connections, simplifying installation and maintenance. With a pin spacing of 10mm, it accommodates a range of conductor sizes and offers flexibility in PCB layout. The terminal block is rated for high voltage and current, making it suitable for demanding environments. Its compact design and robust construction contribute to efficient and dependable performance in industrial automation, power distribution, and control systems.
WAGO 7453202 2-pole PCB Terminal Block Specifications:
- Rated Voltage (III/3): 800 V
- Rated Surge Voltage (III/3): 8 kV
- Rated Voltage (III/2): 1000 V
- Rated Surge Voltage (III/2): 8 kV
- Rated Voltage (II/2): 1000 V
- Rated Surge Voltage (II/2): 8 kV
- Rated Current: 32 A
- Rated Voltage UL (Use Group B): 300 V
- Rated Current UL (Use Group B): 20 A
- Rated Voltage UL (Use Group C): 300 V
- Rated Current UL (Use Group C): 20 A
- Rated Voltage UL (Use Group D): 600 V
- Rated Current UL (Use Group D): 5 A
- Rated Voltage CSA (Use Group B): 300 V
- Rated Current CSA (Use Group B): 20 A
- Rated Voltage CSA (Use Group C): 300 V
- Rated Current CSA (Use Group C): 20 A
- Rated Voltage CSA (Use Group D): 600 V
- Rated Current CSA (Use Group D): 5 A
- Connection Technology: CAGE CLAMP®
- Solid Conductor Size: 0.08 … 4 mm² / 28 … 12 AWG
- Fine-Stranded Conductor Size: 0.08 … 4 mm² / 28 … 12 AWG
- Fine-Stranded Conductor with Ferrule Size: 0.25 … 2.5 mm²
- Strip Length: 8 … 9 mm / 0.31 … 0.35 inch
- Pin Spacing: 10 mm / 0.394 inch
- Width: 16.5 mm
- Height: 23 mm
- Height from Surface: 19 mm / 0.748 inch
- Depth: 19.4 mm
- Solder Pin Length: 4 mm
- Solder Pin Dimensions: 0.8 x 1.2 mm
- Drilled Hole Diameter: 1.5 mm
- Material Group: I
- Insulation Material: Polyamide (PA66)
- Flammability Class: V0
- Clamping Spring Material: Chrome nickel spring steel (CrNi)
- Contact Material: Electrolytic copper (E Cu)
- Contact Plating: tin-plated
- Fire Load: 0.09 MJ
- Weight: 4.8 g
- Pin spacing: 10 mm
- Height from the surface: 19 mm
- Solder pin length: 4 mm
- Solder pin dimensions: 0.8 x 1.2 mm
- Drilled hole diameter with tolerance: 1.5 mm (+0.1)
