WAGO 769106 6-pole Female Plug Connector
The WAGO 769-106 is a 6-pole female plug connector designed for use in electrical distribution systems. It is part of the X-COM system and offers a robust and reliable connection solution. The connector is rated for 500V and 32A, making it suitable for a wide range of industrial applications. It utilizes WAGO’s CAGE CLAMP® connection technology, ensuring a secure and vibration-resistant connection. The female connector is designed to mate with compatible male connectors, facilitating modular and flexible system design. It is ideal for applications requiring frequent connection and disconnection while maintaining high performance and safety standards.
WAGO 769106 6-pole Female Plug Connector Specifications:
- Rated Voltage (III / 3): 500 V
- Rated Impulse Voltage (III / 3): 6 kV
- Rated Current: 32 A
- Connection Technology: CAGE CLAMP®
- Actuation Type: Operating tool
- Connectable Conductor Materials: Copper
- Nominal Cross Section: 4 mm²
- Solid Conductor: 0.08 … 4 mm² / 28 … 12 AWG
- Fine-Stranded Conductor: 0.08 … 4 mm² / 28 … 12 AWG
- Strip Length: 8 … 9 mm / 0.31 … 0.35 inch
- Number of Poles: 6
- Total Number of Connection Points: 6
- Total Number of Potentials: 6
- Type of Wiring: Front-entry wiring
- Width: 30 mm / 1.181 inch
- Height: 45.2 mm / 1.78 inch
- Depth: 18.3 mm / 0.72 inch
- Module Width: 5 mm / 0.197 inch
- Marking Level: Side marking
- Contact Type: Female connector/socket
- Connector Connection Type: for conductors
- Insulating Material: Polyamide 66 (PA 66)
- Fire Load: 0.32 MJ
- Weight: 18.856 g
- Color: gray
- Product Group: 18 (X-COM-System)
- Country of Origin: DE
- GTIN: 4044918471510
- Customs Tariff No.: 85366990990
