WEIDMULLER 1040420000 Wave Solder Edge Connector
The SCDN 3.81/06/90G 3.2SN OR BX is an ultra-flat, two-tier edge connector suitable for wave soldering, featuring compact design with 6 poles and a 90° outgoing elbow. Made by Weidmüller, it supports THT soldering with a 3.81 mm pitch, has tinned copper contacts, and offers space for labeling and coding. It complies with IEC and UL standards, rated for 320V and 17.5A. Ideal for PCB connections, it ensures reliable, high-quality electrical contact in industrial applications, with a safe finger-touch design and a standardized mounting system.
WEIDMULLER 1040420000 Wave Solder Edge Connector Specifications:
- Pitch: 3.81 mm (0.15 inch)
- Number of poles: 6
- Solder pin length: 3.2 mm ±0.02 mm
- Solder pin diameter: 1.0 mm (octagonal)
- Solder eyelet hole diameter: 1.2 mm ±0.1 mm
- Insulating material: PA GF (orange, RAL 2000)
- Contact material: Copper alloy, tinned
- Operating temperature: -50°C to 120°C
- Rated voltage: 320V (IEC), 300V (UL/CSA)
- Rated current: 17.5A (IEC), 10A (UL/CSA)
- Number of solder pins per pole: 1
- Solder eyelet hole diameter: 1.2 mm
- Dimensions: Length at 7.62 mm, width and height compatible with standard PCB design
- Protection: Touch-safe, DIN VDE compliant, safe from finger contact
- Number of rows: 2
- Max. relay or circuit current: 17.5A
- Mounting: THT solder connection, wave soldering compatible
- Flammability: UL 94V-0
Buy the Weidmüller Series BC/SC 3.81: SCDN 3.81/06/90G 3.2SN OR BX
Purchase the Weidmüller Wave Solder Edge Connector online today for reliable and space-efficient PCB connections. Crafted with high-quality tinned copper contacts, it guarantees durability and excellent electrical conductivity. Its 3.81 mm pitch, 6 poles, and 90° outgoing elbow allow for easy access and intuitive wiring. Suitable for wave soldering, this connector meets IEC, UL, and CSA standards, ensuring safety and performance. Perfect for industrial automation, control panels, and electronic device manufacturing, order now to enhance your project with proven quality and seamless installation.
Get Weidmüller SCDN 3.81/06/90G 3.2SN OR BX today—designed for reliable PCB connections with high durability and precise wave soldering compatibility.
