WEIDMULLER 1122810000 TRS 120VUC 1CO Relay Module
The WEIDMULLER TRS 120VUC 1CO relay module is a versatile component for industrial automation and control systems. It offers a robust design with options for screw and tension-clamp connections, AgNi contacts (with optional hard gold plating), and multiple-voltage input. The module includes protective circuits and an illuminated ejection lever for enhanced functionality and ease of use. It is suitable for applications requiring reliable switching and control in demanding environments.
WEIDMULLER 1122810000 TRS 120VUC 1CO Relay Module Specifications:
- Type: TRS 120VUC 1CO
- Order No.: 1122810000
- Version: TERMSERIES, Relay module, Number of contacts: 1 CO contact
- Rated control voltage: 120 V UC ±10 %
- Continuous current: 6 A
- Connection type: Screw connection
- GTIN(EAN): 4032248904860
- Quantity: 10 pc(s).
- Width: 6.4 mm
- Height: 89.6 mm
- Depth: 87.8 mm
- Net weight: 34 g
- Humidity: 5-95% relative humidity
- Operating temperature min: -40 °C
- Storage temperature min: -40 °C
- Operating temperature max: 60 °C
- Storage temperature max: 85 °C
- REACH SVHC: Lead 7439-92-1
- Rated data UL Ambient temperature(operational),max.: 60 °C
- Rated data UL Connection cross-section AWG, max.: AWG 14
- Rated data UL Tightening torque,max.: 0.4 Nm
- Rated data UL Altitude: ≤ 2000 m
- Rated data UL Connection cross-section AWG,min.: AWG 26
- Rated data UL Type of conductor: rigid copper conductor, flexible copper conductor
- Rated data UL Pollution severity level: 2
- Rated data UL Input Rated control voltage: 120 V UC ± 10 %
- Rated data UL Input Rated current DC: 3.5 mA
- Rated data UL Input Pull-in/drop-out voltage, typ.: 89 V / 50 V AC, 100 V/57 V DC
- Rated data UL Input Status indicator: Green LED
- Rated data UL Output Rated switching voltage: 250 V AC
- Rated data UL Output Max. switching voltage,DC: 250 V
- Rated data UL Output Inrush current: 20 A/20 ms
- Rated data UL Output DC switching capacity (resistive),max.: 144 W @ 24 V
- Rated data UL Output Switch-off delay: ≤ 40 ms
- Rated data UL Output Max. switching frequency at rated load: 0.1 Hz
- Rated data UL Contact type: 1 CO contact (AgNi)
- Mechanical service life: 5 x 106 switching cycles
- Rail: TS 35
- Color: black
- Standards: EN 50178, EN 55011, EN 61000-6-1,2,4
- Certificate no. (cULus): E141197
- Certificate No. (DNVGL): TAA00001E5
- Wire connection method: Screw connection
- Clamping range min: 0.14 mm²
- Wire connection cross section AWG, min.: AWG 26
- Wire cross-section solid, min.: 0.14 mm²
- Wire connection cross-section finely stranded, min.: 0.14 mm²
- Wire connection cross-section finely stranded with wire-end ferrules DIN 46228/4, min.: 0.25 mm²
- Conductor cross-section flexible, AEH (DIN 46228-1), min.: 0.25 mm²
- Wire connection cross section, finely stranded, two clampable wires, min.: 0.5 mm²
- Twin wire-end ferrules, min.: 0.5 mm²
