WEIDMULLER 1123250000 Relay Base
The Weidmueller TRS 24VUC 1CO EMPTY is an electromechanical relay base designed for industrial control systems. It features a single contact SPDT (change-over) configuration with a control voltage of 24 V UC ±10%, rated for 10 A current. Its compact dimensions include a width of 6.4 mm, height of 89.6 mm, and depth of 87.8 mm. The base supports screw connections with a tightening torque of 0.4 Nm, suitable for rigid and flexible copper conductors from AWG 26 to AWG 14. It complies with UL, CE, and other standards, and withstands temperature ranges from -40°C to 85°C, making it ideal for diverse automation and control applications.
WEIDMULLER 1123250000 Relay Base Specifications:
- Width: 6.4 mm; Height: 89.6 mm; Depth: 87.8 mm
- Weight: 309 g
- Operating temperature: -40°C to 85°C; Storage temperature: -40°C to 85°C
- Rated control voltage: 24 V UC ±10%; Load voltage: 250 VAC
- Rated current: 10 A; Contact type: 1CO (SPDT)
- Connection: Screw terminal, wire cross section AWG 26–14, min. 0.14 mm², max. 2.5 mm²
- Tightening torque: 0.4 Nm; Stripping length: 8 mm
- Flammability rating: UL 94 V-0; Pollution severity level: 2
- Compliance: UL, RoHS, EN 50178; Surge voltage category: T L, dielectric strength: 4 kV
- Approval: cURus certificate No. E223759
Buy the Weidmueller Series TRS 24VUC 1CO: 1123250000
Purchase the Weidmueller TRS 24VUC 1CO relay base online today and enhance your automation system with this reliable, compact, and easy-to-install control component. Designed for efficient operation, it supports a rated current of 10 A and a control voltage of 24 V UC ±10%. Its screw connection ensures a secure and stable wiring process, supporting wire sizes from AWG 26 to 14. Perfect for industrial applications, this relay base complies with UL, RoHS, and EN standards, offering exceptional durability in temperature ranges from -40°C to 85°C.
Get Weidmueller TRS 24VUC 1CO today—built for precision, reliability, and long-lasting durability.
