WEIDMULLER 1146340000 High Current PCB Header
The OMNIMATE Signal series BL/SL 5.08HC/03/180 is a high-current PCB male header with 3 poles, designed for reliable wave soldering. Made from orange PA GF dielectric material, it features a 5.08 mm pitch, 3.2 mm solder pin length, and durable nickel and tin-plated contact surfaces. Suitable for industrial wiring, it supports a maximum rated current of 24A and voltage of 400V in IEC standards, with UL approval for 18.5A at 300V. Its robust design ensures secure, maintenance-friendly connections in various electronic assemblies.
WEIDMULLER 1146340000 High Current PCB Header Specifications:
- Pitch: 5.08 mm (0.2 inch)
- Number of poles: 3
- Solder pin length: 3.2 mm ±0.1/-0.3 mm
- Solder eyelet hole diameter: 1.3 mm ±0.1 mm
- Contact material: CuMg with Ni/Sn layer
- Insulating material: PA GF, orange, RAL 2000
- Rated current: 24A (IEC), 18.5A (UL)
- Rated voltage: 400 V (IEC), 300 V (UL)
- Operating temperature: -50°C to 100°C
- Solder pin dimensions: d=1.2 mm, octagonal
- Pluggable up to 25 cycles
- UL and IEC certified, RoHS conform
Buy the Weidmiller 1146340000 – Reliable PCB Connector for Industrial Applications
Order the Weidmiller 1146340000 high-current PCB header online today for reliable, high-performance connections in industrial electronics. Designed with a 5.08 mm pitch and robust nickel/tin-plated contacts, this 3-pole male header supports up to 24A current and 400V voltage ratings, meeting IEC and UL standards. Its orange PA GF insulation offers excellent durability and resistance to environmental factors, making it ideal for PCB assembly, automation, and control systems. Purchase online now to ensure quick delivery and dependable quality.
Get Weidmiller 1146340000 today—built for durable, high-current electronic connections in industrial environments.
