WEIDMULLER SL351090G PCB Pin Header
The OMNIMATE Signal series SL 3.50 PCB pin header is designed for wave soldering with a 3.50 mm pitch, featuring 10 poles and a 90° plugging direction. Made with tinned copper contacts and a PBT housing in orange, it ensures reliable electrical connection with UL and IEC safety approvals. The connector supports practical wave soldering profiles and is suitable for use in industrial electronics, automation, and control systems. Its robust construction offers high durability and ease of installation for PCB mounting and signal distribution applications.
WEIDMULLER SL351090G PCB Pin Header Specifications:
- Pitch: 3.5 mm (0.138 inch)
- Number of poles: 10
- Solder pin length: 3.2 mm (+0.1/-0.3 mm)
- Contact material: CuSn, Tinned
- Housing material: PBT, orange, RAL 2000
- Solder eyelet hole diameter: 1.4 mm
- Pin dimensions: d=1.2 mm, octagonal
- Number of solder pins per pole: 1
- Touch-safe protection: DIN VDE compliant
- Rated voltage (UL/IEC): 300V
- Rated current: 10A (max per IEC/CSA)
- Temperature range: -30°C to 100°C
- Flammability: UL 94 V-0
- Layer structure: Nickel and Tin coating
- Packaging: Box, 50 poles
- Plugging cycles: Up to 25
- Push-in force: 10 N per pole
- Withdrawal force: 8 N per pole
Buy the Buy Weidmüller Signal PCB Pin Header Part Number SL351090G Online
Enhance your electronics projects with the reliable Weidmüller PCB pin header. Designed for wave soldering, it features 10 poles with a 3.50 mm pitch, a robust copper contact, and a durable PBT orange housing. It is UL and IEC approved, supporting safety and quality standards. Perfect for industrial automation and control system applications, this male header offers easy PCB mounting, multiple plugging cycles, and high-temperature tolerance. Order online today for fast delivery and dependable performance in your electrical assemblies.
Order your Weidmüller Series SL351090G PCB pin header today and ensure reliable, secure connections in your industrial or control systems.
