WEIDMULLER 1146750000 PCB Header Connector
The SL 5.08HC/03/180G 3.2SN OR BX is a 3-pole, PCB-connector male header designed for reliable soldering onto circuit boards. It features a 5.08 mm pitch, high current capacity, and corrosion-resistant tin-plated contacts. Its glass-fiber-reinforced plastic housing ensures durability and optimal wave soldering performance. The connector's compact design, with a 3.2 mm solder pin length, makes it suitable for various electronic applications, offering robust mechanical and electrical connection with UL and IEC certifications for safety and quality.
WEIDMULLER 1146750000 PCB Header Connector Specifications:
- Pitch: 5.08 mm (0.2 inch)
- Number of poles: 3
- Solder pin length: 3.2 mm (+0.1 / -0.3 mm)
- Solder eyelet hole diameter: 1.3 mm (+0.1 mm)
- Material: PA GF (glass-filled polyamide)
- Insulation resistance: > 10^9 Ω
- Operating temperature: -50°C to 100°C
- Rated current: 24A per IEC, 18.5A per UL
- Rated voltage: 400V IEC, 300V UL
- Color: Orange (RAL 2000)
- Contact material: CuMg with Ni/ Sn surface layers
- UL V0 flammability rating
- Max. number of plugging cycles: 25
Buy the Buy Weidmueller Signal Series SL 5.08HC/03/180G Part Number 1146750000 Online
Order the Weidmueller Signal Series PCB header connector online today to ensure a secure, durable electrical connection in your electronic projects. This 3-pole component with a 5.08 mm pitch features tin-plated contacts, high current capacity, and robust design to meet industrial standards. Its glass-fiber-reinforced housing guarantees mechanical strength and excellent wave soldering properties. Perfect for automated PCB assembly, this connector supports up to 25 insertion cycles, providing a reliable and long-lasting connection for your electronic systems.
Buy Weidmueller Signal Series SL 5.08HC/03/180G Part Number 1146750000 now and benefit from high current capacity and proven reliability for your electronic connections.
