WEIDMULLER 1146910000 High-Current PCB Header
The SL 5.08HC/10/180G 3.2SN OR BX is a high-current, 10-pole PCB male header designed for reliable electrical connections in electronic assemblies. It features a 5.08 mm pitch with a 3.2 mm solder pin length, optimized for wave soldering processes, and has a tinned, octagonal contact pin made of copper alloy with nickel and tin layers. The connector's orange polyamide insulation provides high durability and heat resistance, supporting applications up to 100°C with UL and IEC approvals. Suitable for industrial automation and electronic device manufacturing, it ensures secure, soldered connections with a maximum rated current of 24A and voltage of 400V. Its robust design and proven specifications make it ideal for demanding electronic projects.
WEIDMULLER 1146910000 High-Current PCB Header Specifications:
- Pitch: 5.08 mm (0.2 inch)
- Number of poles: 10
- Solder pin length: 3.2 mm ±0.1/-0.3 mm
- Solder pin diameter: 1.2 mm, octagonal, tin-plated CuMg contact surface
- Eyelet hole diameter: 1.3 mm ±0.1 mm
- Insulating material: PA GF, orange color (RAL 2000), flammability rating UL 94 V0
- Rated voltage: 400 V (IEC), 300 V (UL)
- Rated current: 24 A (IEC), 18.5 A (UL)
- Operating temperature: -50°C to 100°C
- Maximum temperature during soldering: 260°C
- Number of solder pins per pole: 1
- Plugging cycles: 25
- Certification: UL, IEC, CSA
- Dimensions: length 45.72 mm (1.8 inch)
- Material: Polyamide GF, tinned copper alloy contacts
- Storage temperature: -25°C to 55°C
- Humidity: Max 80% during storage
Buy the Buy Weidmueller SL 5.08HC/10/180G 3.2SN OR BX Part Number 1146910000 Online
Purchase the Weidmueller High-Current PCB Header Series SL 5.08HC/10/180G 3.2SN OR BX today through online stores. This robust 10-pole connector features a 5.08 mm pitch and is designed for demanding electronic applications. The connector's durable orange insulation is UL 94 V0 rated, with copper alloy contacts that are tin-plated for reliable soldering. It supports a maximum rated current of 24A and voltage of 400V, ensuring high performance in industrial automation, electronics manufacturing, and control systems. Easy to install, with a proven lifespan of 25 plugging cycles, it guarantees secure, durable electrical connections for your projects.
Order your Weidmueller Series SL 5.08HC/10/180G 3.2SN OR BX today and secure reliable, high-current electrical connections optimized for wave soldering.
