WEIDMULLER 1147920000 High-current PCB Connector
The SL 5.08HC/03/180LF 3.2SN OR BX is a high-current PCB plug-in connector designed with a THT solder connection and an orange insulating PA GF material. It features a 5.08 mm pitch, 3 poles, and a solder pin length of 3.2 mm, optimized for wave soldering processes. Its compact design includes a solder eyelet hole of 1.3 mm diameter and allows up to 25 plugging cycles. Certified for 400 V/24 A IEC standards and UL rated, this connector ensures reliable electrical performance in industrial applications.
WEIDMULLER 1147920000 High-current PCB Connector Specifications:
- Pitch: 5.08 mm (0.2 inches)
- Number of poles: 3
- Solder pin length: 3.2 mm, tolerance +0.1/-0.3 mm
- Solder eyelet hole diameter: 1.3 mm
- Insulating material: PA GF, orange color (RAL 2000)
- Contact material: Copper alloy with Ni/Sn layers
- Rated voltage: 400 V IEC, 300 V UL
- Rated current: 24 A IEC, 18.5 A UL
- Operating temperature: -50°C to 100°C
- Max. storage humidity: 80%
- Number of soldering cycles: 25
- UL flammability rating: V0
- Storage temperature: -25°C to 55°C
- Max. line mounting length: approximately 10.16 mm
- Mounting: THT solder connection, box packaging
- Approvals: IEC, UL, cURus
- Color: Orange, similar to RAL 2000
Buy the Weidmueller Series OMNIMATE Signal: SL 5.08HC/03/180LF 3.2SN OR BX
Order the Weidmueller High-current PCB connector today to ensure durable, reliable connections for industrial PCBs. With a robust THT solder process, orange insulating material, and IEC and UL certifications, this 3-pole connector with a 5.08 mm pitch offers excellent performance in demanding environments. Its compact design accommodates 25 soldering cycles, making it ideal for versatile electronic assemblies. Enhance your projects with a proven, certified component that meets global safety and performance standards, available now for quick online purchase.
Get Weidmueller SL 5.08HC/03/180LF 3.2SN OR BX today—built for reliable electrical connections and industrial efficiency.
