WEIDMULLER 1176050000 Signal Isolator
The ACT20M-2CI-2CO-OLP-S is a highly reliable, space-saving passive isolator designed for current signal conversion and galvanic isolation in industrial automation. It isolates standard analog current signals with high precision, ensuring signal integrity and interference resistance. Suitable for ATEX and IECEX zones, it is DIN rail mounted and powered via the output loop. With two isolated channels, it guarantees safety and consistent performance in hazardous environments. Its compact dimensions and low power consumption make it ideal for industrial control and monitoring systems.
WEIDMULLER 1176050000 Signal Isolator Specifications:
- Dimensions: Width 6.1mm, Height 112.5mm, Depth 114.3mm
- Weight: 96.9g
- Input: 2 sensor current sources, 4-20 mA, typical voltage drop 2.5 V, frequency 100 Hz
- Output: 2 current outputs 4-20 mA, load impedance < 600Ω, cut-off frequency @ 100Hz
- Supply Voltage: 6-35 V DC, loop powered, max. power consumption 50mW per channel
- Isolation: 2-way galvanic isolation with maximum insulation voltage 2.5 kV, pollution severity level 2
- Temperature Range: Operating -25°C to +70°C, Storage -40°C to +85°C
- Accuracy: < 0.05% of measurement
- Standards: IEC 61326-1, NE 21, IEC61010-1
- Protection: Suitable for Ex applications, ATEX, IECEx, UL certified
- Connection: Screw terminal, tighten torque 0.4-0.6 Nm, wire size AWG 30 to 14
Buy the Weidmueller ACT20M-2CI-2CO-OLP-S – Reliable Signal Converter for Industrial Applications
Get the Weidmueller ACT20M-2CI-2CO-OLP-S today and improve signal integrity and safety in your industrial automation setup. This high-quality, two-channel passive isolator easily mounts on DIN rails, providing galvanic isolation for analog current signals in hazardous environments. It is designed for easy installation, low power consumption, and compliance with international safety standards like ATEX and IECEx. Whether for monitoring, automation, or control applications, this reliable isolator ensures precise signal transmission and robust performance, making it a valuable addition to your industrial toolbox.
Order your Weidmueller ACT20M-2CI-2CO-OLP-S today and enhance your industrial control systems with reliable, high-precision current isolation technology.
Frequently Asked Questions
Where can I buy WEIDMULLER 1176050000?
You can click on the BUY or RFQ button to purchase 1176050000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1176050000?
You can download the 1176050000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1176050000?
WEIDMULLER
