WEIDMULLER 2014420000 PCB Terminal Block
The LUP 12.70/05/90 series PCB terminal provides a reliable connection for conductors up to 16 mm², supporting voltages up to 1000 V and currents up to 76 A. It features a proven clamping yoke connection, a 12.7 mm pitch, and a 90° outlet conductor design. Suitable for PCB mounting with THT soldering, it offers high insulation, UL, IEC, and CSA certification, and is designed for easy assembly with multiple conductor options, including fine and stranded wires. Ideal for industrial and power engineering applications requiring durable, high-current connections with compact size.
WEIDMULLER 2014420000 PCB Terminal Block Specifications:
- Width: 61.76 mm
- Height: 36.5 mm
- Depth: 25.1 mm
- Pitch: 12.7 mm (0.5 inch)
- Number of poles: 5
- Solder pin length: 5 mm
- Conductor cross-section: 0.5-16 mm², AWG 22- AWG 6
- Rated voltage: IEC 1000 V, UL 600 V, CSA 600 V
- Rated current: IEC 76 A, UL and CSA 65 A
- Clamping range: min 0.13 mm², max 16 mm²
- Tinned copper contact surface
- Ambient operating temperature: -50°C to +120°C
- Flammability rating: UL 94V-0
- Insulating material: Wemid (PA), black color
- Cable outlet: 90° conductor outlet
- Tightening torque: min 1.2 Nm, max 1.5 Nm
- Protection class: IP20 plugged, IP10 unplugged
Buy the Weidmüller Series LUP PCB Terminal: 2014420000
Purchase the Weidmüller Series LUP PCB terminal now to enjoy a robust, high-current connection solution suitable for industrial power distribution. With UL, IEC, and CSA approvals, it guarantees safety and compliance for your electrical systems. Featuring a compact size of 12.7 mm pitch, support for conductors up to 16 mm², and proven clamping yoke connection technology, this terminal guarantees easy installation and durable operation in demanding environments. Buy online today for fast delivery and trusted quality.
Order your Weidmüller Series LUP PCB terminal today and ensure reliable high-current connections for your electrical projects.
Frequently Asked Questions
Where can I buy WEIDMULLER 2014420000?
You can click on the BUY or RFQ button to purchase 2014420000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 2014420000?
You can download the 2014420000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 2014420000?
WEIDMULLER
