WEIDMULLER 1234580000 PCB Terminal
This PCB terminal features a pressure clamp connection with a 5.08 mm pitch and 6 poles, suitable for conductor cross-sections up to 2.5 mm². It offers a secure connection with a 90° outlet direction, tinned solder pins, and a compact design. Rated for 600 V and 24 A according to IEC standards, it ensures reliable electrical performance in industrial applications. The terminal has an orange insulating housing made of Wemid (PA), with UL and IEC certifications. Easy to install on PCB with recommended wave soldering profiles, ideal for automation and control systems.
WEIDMULLER 1234580000 PCB Terminal Specifications:
- Pitch: 5.08 mm (0.2 inch)
- Number of poles: 6
- Solder pin length: 3.5 mm
- Maximum conductor cross-section: 2.5 mm²
- Rated voltage: IEC 600 V, UL 300 V
- Rated current: IEC 24 A, UL 15 A
- Conductor outlet direction: 90°
- Insulating material: Wemid (PA), Orange color
- Contact material: Copper alloy, tinned
- Clamping method: Pressure clamp connection
- Wire cross-section (solid): 0.13 - 2.5 mm² (AWG 26 - 14)
- Operating temperature: -60°C to 120°C
- Flammability rating: UL 94 V-0
- Certifications: IEC, UL, CSA
- Storage temperature: -25°C to 55°C
- Dimensions: Length varies with model, typical pin length 3.5 mm
- Tinning thickness: 1-3.5 μm Ni, 4-6 μm Sn
Buy the Weidmueller 1234580000 – Reliable Electrical Connection for Industrial Applications
Enhance your industrial wiring projects with this reliable PCB terminal featuring a 6-pole pressure clamp connection, rated for 600 V and 24 A. Its compact design and easy PCB mounting make it ideal for automation, control, and wiring systems. Made of durable Wemid (PA) housing, with tinned copper contacts, it ensures safe and durable electrical connections. Certified according to IEC, UL, and CSA standards, it offers excellent performance in demanding environments. Purchase online today to streamline your assembly process with trusted, high-quality components.
Order your Weidmueller Series 6-Pole PCB Terminal today and give your projects the dependable quality they deserve with easy installation and certified safety.
Frequently Asked Questions
Where can I buy WEIDMULLER 1234580000?
You can click on the BUY or RFQ button to purchase 1234580000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1234580000?
You can download the 1234580000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1234580000?
WEIDMULLER
