WEIDMULLER 1251310000 Power Decoupling Module
The PRO DM 10 is a diode module designed for decoupling outputs of switched-mode power units, providing protection and redundancy in electrical systems. It ensures safe doubling of power output, critical load supply, and energy recovery protection. The module features a compact, robust metal housing, operating within temperatures of -40°C to +70°C, with high efficiency exceeding 97%. It supports screw connection input/output with a rated voltage of 24V DC, delivering up to 24A continuous output current. Suitable for industrial automation and power systems, it offers surge protection, anti-inverse voltage features, and IP20 protection class, ensuring reliable long-term operation in demanding environments.
WEIDMULLER 1251310000 Power Decoupling Module Specifications:
- Dimensions: Width 32mm, Height 125mm, Depth 125mm
- Net weight: 518g
- Operating temperature: -40°C to 70°C
- Housing: Metal, corrosion resistant
- Input voltage: 0-60V DC, Rated 24V DC
- Input current: 12A (-40°C to +45°C), 10A (+45°C to +60°C), 7.5A (+70°C)
- Output current: 24A (40°C to +45°C), 20A (+45°C to +60°C), 15A (+70°C)
- Output voltage: 24V DC, Residual ripple: dependent on power supply used
- Efficiency: > 97% at 24V input
- Protection: IP20, Surge voltage category
- Vibration resistance: IEC 60068-2-6, 2.3g
- Shock resistance: IEC 60068-2-27, 30g
- Insulation voltage: 0.5kV input/earth and output/earth
- Connection: Screw terminals, max conductor cross-section AWG 10 min. 26, flexible min. 0.22mm, rigid max. 6mm
Buy the Weidmueller PRO DM 10 – Reliable Power Decoupling Module for Industrial Applications
The Weidmueller PRO DM 10 diode module offers exceptional protection and redundancy for switched-mode power units in industrial environments. Designed with a robust metal casing, it supports up to 24V DC input and provides up to 24A continuous output current, making it ideal for critical power applications. Its high efficiency, surge protection, and simple screw connection system ensure reliable long-term operation. Suitable for automation systems, energy recovery, and power doubling, it is a vital component for ensuring system stability and safety in demanding industrial settings.
Get Weidmueller PRO DM 10 today—built for precision and long-lasting durability in power distribution systems.
