WEIDMULLER 125966 Signal Connector

WEIDMULLER 125966 Signal Connector Specifications:

• Deliverystatus: This article will no longer be available in the future.
• Available until: 2017-12-31
• Type: BL 5.08/07/180 SN OR BX
• Order No.: 1716370000
• Version: PCB plug-in connector, female plug, 5.08 mm, No. of poles: 7, 180°, Pressure clamp connection, Clamping range, rated connection, max.: 2.08 mm², Box
• GTIN(EAN): 4008190376406
• Qty.: 50pc(s).
• Product data IEC: 400 V / 14 A / 0.2 - 1.5 mm²
• Product data UL: 300 V/10 A/AWG 26 - AWG 14
• Packaging: Box
• Alternative product: 1943630000
• Net weight: 10.22 g
• Product family: OMNIMATE Signal - series BL/SL 5.08
• Conductor outlet direction: 180°
• Pitch in inches: 0.2 inch
• Pluggingcycles: 25
• Screwdriver blade standard: DIN 5264
• Tighteningtorque,max.: 0.5 Nm
• Strippinglength: 6 mm
• L1 in inches: 1.2 inch
• Volume resistance: 4.60 mΩ
• Wire connection method: Pressure clampconnection
• Pitch in mm: 5.08 mm
• No. of poles: 7
• Screwdriver blade: 0.6 x 3.5
• Tighteningtorque,min.: 0.4 Nm
• Clampingscrew: M 2.5
• L1 in mm: 30.48 mm
• Touch-safe protection: DIN VDE 0470 IP 00
• Insulatingmaterial: PA
• Colour chart: RAL 2000
• CTI: ≥ 600
• Contact surface: tinned
• Operatingtemperature,min.: -50 °C
• Temperature range,installation,min.: -25 °C
• Storage temperature, min.: -25 °C
• Colour: Orange
• UL 94 flammabilityrating: V-2
• Contact material: CuSn
• Layer structure ofplugcontact: 4-8µm Sn hot-diptinned
• Operatingtemperature,max.: 100 °C
• Temperature range,installation,max.: 100 °C
• Storage temperature, max.: 55 °C
• Clampingrange,rated connection,min.: 0.13 mm²
• Wire connection cross section AWG,min.: AWG 26
• Solid,min. H05(07)V-U: 0.2 mm²
• Flexible,min. H05(07)V-K: 0.2 mm²
• w. wire end ferrule, DIN 46228 pt 1, min: 0.2 mm²
• w. plastic collar ferrule, DIN 46228 pt 4, min: 0.2 mm²
• Plug gauge acc. to EN 60999 a x b; Ø: 2.4 mm x 1.5 mm
• Clampingrange,rated connection,max.: 2.08 mm²
• Wire connection cross section AWG,max.: AWG 14
• Solid,max. H05(07)V-U: 1.5 mm²
• Flexible,max. H05(07)V-K: 1.5 mm²
• w. wire end ferrule, DIN 46228 pt 1, max: 1.5 mm²
• w. plastic collar ferrule, DIN 46228 pt 4, max: 1 mm²
• Rated current, min. no. of poles (Ta = 20°C): 14 A
• Rated current, min. no. of poles (Ta = 40°C): 12 A
• Rated voltage for surge voltage class / pollution degree II/2: 400 V
• Rated voltage for surge voltage class / pollution degree III/3: 250 V
• Rated impulse voltage for surge voltage class/ pollution degree III/2: 4 kV
• Rated current, max. no. of poles (Ta = 20°C): 12 A
• Rated current, max. no. of poles (Ta = 40°C): 10 A
• Rated voltage for surge voltage class / pollution degree III/2: 320 V
• Rated impulse voltage for surge voltage class/ pollution degree II/2: 4 kV
• Rated impulse voltage for surge voltage class/ contamination degree III/3: 4 kV
• Institute (CSA): Rated voltage(UsegroupB) 300 V
• Certificate No. (CSA): 200039-1027343
• Institute (UR): Rated voltage(usegroupB) 300 V
• Certificate No. (UR): E60693
• IPC conformity: The products are developed, manufactured and delivered according to the internationally recognised IPC-A-610 standard, category "permissible"
