WEIDMULLER 1335370000 Signal Connector

WEIDMULLER 1335370000 Signal Connector Specifications:

• Type: SLF 5.08/06/180 SN OR BX
• Order No.: 1335370000
• Version: PCB plug-in connector, male plug, 5.08 mm, No. of poles: 6, 180°, PUSH IN
• Clamping range: max. : 3.31 mm²
• GTIN(EAN): 4050118138726
• Quantity: 60pc(s).
• Product data (IEC): 400 V / 25.9 A / 0.2 - 2.5 mm²
• Product data (UL): 300 V/14 A/AWG 26 - AWG 12
• Packaging: Box
• Pitch in mm: 5.08 mm
• Conductor outlet direction: 180°
• L1 in mm: 25.4 mm
• Pin seriesquantity: 1
• Touch-safe protection: acc. to DIN VDE 57 106
• Finger-safe: plugged/ back-of-hand-safe unplugged
• Can be coded: Yes
• Screwdriver blade: 0.6 x 3.5
• Plugging cycles: 25
• Wire connection method: PUSH IN
• Pitch in inches: 0.2 inch
• No. of poles: 6
• L1 in inches: 1 inch
• Rated cross-section: 2.5 mm²
• Volume resistance: 4.50 mΩ
• Strippinglength: 10 mm
• Screwdriver blade standard: DIN 5264
• Insulating material: PBT
• Colour: Orange
• Colour chart (similar): RAL 2000
• Insulation resistance: ≥ 108Ω
• UL 94 flammability rating: V-0
• Contact material: CuSn
• Contact surface: tinned
• Layer structure of plug contact: 4-8µm Sn hot-diptinned
• Storage temperature, min.: -25 °C
• Storage temperature, max.: 55 °C
• Max. relative humidity during storage: 80 %
• Operating temperature, min.: -50 °C
• Operating temperature, max.: 100 °C
• Temperature range, installation, min.: -25 °C
• Temperature range, installation, max.: 100 °C
• Clamping range, min.: 0.13 mm²
• Wire connection cross section AWG, min.: AWG 26
• Solid, min.: H05(07)V-U 0.2 mm²
• Flexible, min.: H05(07)V-K 0.2 mm²
• w. plastic collar ferrule, min.: 0.2 mm²
• w. wire end ferrule, min.: 0.2 mm²
• Plug gauge: 2.8 mm x 2.0 mm
• Clamping range, max.: 3.31 mm²
• Wire connection cross section AWG, max.: AWG 12
• Solid, max.: H05(07)V-U 2.5 mm²
• Flexible, max.: H05(07)V-K 2.5 mm²
• w. plastic collar ferrule, max.: 2.5 mm²
• w. wire end ferrule, max.: 2.5 mm²
• Rated current, max. no. of poles (Tu=20°C): 21.7 A
• Rated current, max. no. of poles (Tu=40°C): 18.5 A
• Rated voltage for surge voltage class / pollution degree III/2: 320 V
• Rated impulse voltage for surge voltage class/ pollution degree II/2: 4 kV
• Rated impulse voltage for surge voltage class/ contamination degree III/3: 4 kV
• Rated current, min. no. of poles (Tu=20°C): 25.9 A
• Rated current, min. no. of poles (Tu=40°C): 22.5 A
• Rated voltage for surge voltage class / pollution degree II/2: 400 V
• Rated voltage for surge voltage class / pollution degree III/3: 250 V
• Short-time withstand current resistance: 3 x 1s with 120 A
• Institute (CSA): Rated voltage(UsegroupB) 300 V
• Certificate No. (CSA): 200039-1121690
• Rated voltage(usegroupD): 300 V
• Reference to approval values: Specifications are maximum values, details - see approval certificate
• Institute (cURus): Rated voltage(usegroupB) 300 V
• Certificate No. (cURus): E60693
