WEIDMULLER 1356900000 PCB Terminal Block
The Weidmuller OMNIMATE Signal LL 6.35/08/90V 5.0SN BK BX is a PCB terminal block designed for reliable connections in a variety of industrial applications. It offers a 6.35mm pitch, 8 poles, and a 90° conductor outlet direction, providing flexibility in circuit board layout. The clamping yoke connection ensures secure wire termination, while the robust construction supports ratings of 1000V and 32A. Suitable for applications requiring high voltage and current handling, this terminal block is a dependable choice for power distribution and signal transmission.
WEIDMULLER 1356900000 PCB Terminal Block Specifications:
- Base Material: Copper alloy
- Insulating Material: Wemid (PA)
- Color: Black
- Flammability Rating: V-0
- Contact Surface: tinned
- Storage Temperature Min: -25 °C
- Storage Temperature Max: 55 °C
- Operating Temperature Min: -50 °C
- Operating Temperature Max: 120 °C
- Pitch: 6.35 mm
- Number of Poles: 8
- Conductor Outlet Direction: 90°
- Solder Pin Length: 5 mm
- Clamping Range Min: 0.18 mm²
- Clamping Range Max: 6 mm²
- Rated Voltage IEC: 1000 V
- Rated Current IEC: 32 A
- Rated Voltage UL: 600 V
- Rated Current UL: 30 A
- Solid Conductor Max: 6 mm²
- Flexible Conductor Max: 4 mm²
- Wire Connection Cross Section AWG Min: 26 AWG
- Wire Connection Cross Section AWG Max: 10 AWG
- Short-Time Withstand Current: 120 A
- Insulation Resistance: ≥ 108Ω
- Touch-Safe Protection: DIN VDE 0470, DIN VDE 57 106
