WEIDMULLER 1386700000 Power PCB Terminal
The LXXX 15.00/08/90 power PCB connection terminal is designed for high-current applications, offering a reliable connection for power electronics. It features an 8-pole, solder pin connections, and a clamping yoke for secure wiring. With a maximum clamping range of 50 mm², it supports currents up to 150 A at 1000 V IEC standards, making it ideal for demanding power distribution and control projects. Its compact, robust design ensures durability, ease of installation, and enhanced system safety for industrial and automation applications.
WEIDMULLER 1386700000 Power PCB Terminal Specifications:
- Number of poles: 8
- Rated Voltage IEC: 1000 V
- Rated Current IEC: 150 A
- Max Clamping Range: 50 mm²
- Solder Pin Length: 4.5 mm
- Solder Pin Dimensions: 12 x 1.2 mm
- Material: Copper alloy contact, PA insulation (black, RAL 9011)
- Flammability rating: UL 94 V0
- Operating Temperature: -50°C to 120°C
- Dimensions: Width 121 mm, Height 56 mm, Depth 31 mm
- Weight: 238.82 g
- Wire connection method: Clamping yoke, THT solder connection
- Pitch: 15 mm
- Tightening Torque: 2.5 Nm to 4 Nm
- Compatible wire AWG: 20 to 1
- Insulation withstanding voltage: 210° ins. strength
- Certification: IEC, UL, CSA
Buy the Weidmueller 1386700000 – Reliable Power PCB Terminal for Industrial Applications
Secure your power distribution systems with the Weidmueller LKXX power PCB terminal. Designed for high-current demand, it ensures reliable connections up to 150 A/1000 V. Its compact size and robust construction simplify installation and maintenance in industrial environments. Ideal for automation, control panels, and power electronics, this module delivers safety and efficiency. Purchase online today to benefit from trusted quality, fast delivery, and expert support for your power management needs in demanding applications.
Order your Weidmueller Series LKXX power PCB terminal today and enhance your power electronics projects with reliable, high-current connection technology.
