WEIDMULLER 1478210000 70W 5V 14A Power Supply
The Weidmuller PRO MAX 70W 5V 14A switch-mode power supply is engineered for robust performance in demanding automation environments. It provides reliable power with continuous overload capacity up to 20% and peak loads of 300%. Its wide temperature range operation, low width, and compatibility with uninterruptible DC USPs, diode modules, and CAP modules allow for customized power solutions. The unit features a wide input voltage range, surge protection, and a floating contact for enhanced safety and versatility.
WEIDMULLER 1478210000 70W 5V 14A Power Supply Specifications:
- Base Part Number: 1478210000
- Version: Power supply, switch-mode power supply unit, 5 V
- GTIN (EAN): 4050118285987
- Quantity: 1 pc(s).
- Width: 32 mm
- Height: 130 mm
- Depth: 125 mm
- Net Weight: 650 g
- Width (inches): 1.26 inch
- Height (inches): 5.118 inch
- Depth (inches): 4.921 inch
- Humidity at Operating Temperature: 5...95 %, no condensation
- Operating Temperature Min: -25 °C
- Storage Temperature Min: -40 °C
- Storage Temperature: -40 °C...85 °C
- Operating Temperature Max: 70 °C
- Storage Temperature Max: 85 °C
- AC Current Consumption: 1 A @ 230 V AC / 1.5 A @ 115 V AC
- Connection System (Input): Screw connection
- DC Input Voltage Range: 80...370 V DC
- Input Fuse: Yes
- Rated Input Voltage: 100...240 V AC (wide-range input)
- Standby Power Consumption: 1 W
- AC Input Voltage Range: 85…277 V AC
- DC Current Consumption: 1A @ 370 VDC / 1,5A @ 120 VDC
- Frequency Range AC: 45…65 Hz
- Inrush Current: max. 15 A
- Recommended Back-up Fuse: 6 A, Char. B, circuit breaker, 3 - 5 A Char. C, circuit breaker
- Surge Protection: Varistor
- Output Power: 70 W
- Output Voltage: 5 V
- Power Reserve at Nom. Voltage: 16.8 A(1 min), 21 A(4s)
- Pulsed Current Capacity @ URated: 42 A(2ms)
- Rated Output Voltage: 5 V DC
- Continuous Output Current @ URated: 16,8 A @ 45°C, 10,5 A @ 70°C
- Parallel Connection Option: yes, max. 5
- Protection Against Inverse Voltage: Yes
- Rated (Nominal) Output Current @ UNom: 14 A @ 60°C
- Residual Ripple: < 50 mVss @ UNenn, Full Load
- Current Limiting: > 120 % IN
- Derating: > 60°C/75% @ 70°C
- Housing Version: Metal, corrosion resistant
- Mounting Position: Horizontal on TS35 mounting rail
- Power Factor: > 0.90 @ 230 V AC
- Power Loss Nominal Load: 11.7 W
- Protection Degree: IP20
- Short-Circuit Protection: Yes
- Status Indication: LED red/green and relay
- Interference Immunity Test: EN 55024, EN 55022, IEC61000-3-2,-3, IEC61000-4-2,-3,-4,-5,-6,-8,-11
- Insulation Voltage Output/Earth: 0.5 kV
- Pollution Severity: 2
- Electrical Machine Equipment: Acc. to EN60204
- Protective Separation: VDE0100-410 / acc. to DIN57100-410
- Conductor Cross-Section AWG/kcmil Min (Input): 26
- Conductor Cross-Section Rigid Max (Input): 6 mm²
- Tightening Torque Min (Input): 0.5 Nm
- AC Failure Bridging Time: min. 20 ms
- Degree of Efficiency: 86%
- Earth Leakage Current: max. 3.5 mA
- MTBF: >500.000h (25°C, IEC 61709)
- Operating Temperature: -25 °C...70 °C
- Power Loss Idling: 1 W
- Protection Against Reverse Voltages from Load: > 7.5 V DC
- Series Switching Capability: Yes
- Start-up: ≥ -40 °C
- Surge Voltage Category: III
- Vibration Resistance: 2.3g
- Shock Resistance: 30 g in all directions
- Insulation Voltage Input/Earth: 3.5 kV
- Insulation Voltage Input/Output: 4 kV
