WEIDMULLER 1890260000 Female Plug Connector
The WEIDMULLER OMNIMATE Signal BL/SL 5.08 BLT 5.08HC/06/180LR SN OR BX is a PCB plug-in connector designed for reliable and efficient wire connections. This female connector utilizes a TOP screw connection system, providing a secure and easily accessible connection point. The release latch mechanism enhances usability, while the ability to code connectors allows for organized and error-free assembly. Suitable for a wide range of industrial applications, this connector offers robust performance and ease of integration into existing systems. It is ideal for applications requiring high current capacity and secure connections.
WEIDMULLER 1890260000 Female Plug Connector Specifications:
- Type: BLT 5.08HC/06/180LR SN OR BX
- Order No.: 1890260000
- Version: PCB plug-in connector, female plug, 5.08 mm, No. of poles: 6, 180°, TOP connection, Clamping range, max. : 2.5 mm²
- GTIN(EAN): 4032248498741
- Quantity: 42pc(s).
- Product data (IEC): 400 V / 27 A / 0.2 - 2.5 mm²
- Product data (UL): 300 V/17 A/AWG 26 - AWG 14
- Packaging: Box
- Net weight: 20.81 g
- Product family: OMNIMATE Signal - series
- Wire connection method: TOP connection
- Pitch in inches: 0.2 inch
- No. of poles: 6
- L1 in inches: 1 inch
- Pin seriesquantity: 1
- Touch-safe protection: Safe from finger touch
- Coded: Yes
- Tightening torque (min): 0.4 Nm
- Clampingscrew: M 2.5
- Screwdriver blade standard: DIN 5264
- Push-in force/pole: 10 N
- Pitch in mm: 5.08 mm
- Conductor outlet direction: 180°
- L1 in mm: 25.4 mm
- Number of rows: 1
- Rated cross-section: 2.5 mm²
- Volume resistance: 4.50 mΩ
- Stripping length: 13 mm
- Tightening torque (max): 0.5 Nm
- Plugging cycles: 25
- Withdrawal force per pole: 8 N
- Insulating material: PBT
- Colour: Orange
- Insulating material group: IIIa
- Insulation resistance: ≥ 108Ω
- Contact material: CuSn
- Contact surface: tinned
- Storage temperature (min): -25 °C
- Max. relative humidity during storage: 80 %
- Operating temperature (max): 100 °C
- Temperature range (installation, max): 100 °C
- Clamping range (min): 0.13 mm²
- Wire connection cross section AWG (min): AWG 28
- Solid wire (min): 0.2 mm²
- Flexible wire (min): 0.2 mm²
- Wire with plastic collar ferrule (min): 0.2 mm²
- Wire end ferrule (min): 0.2 mm²
- Clamping range (max): 2.5 mm²
- Wire connection cross section AWG (max): AWG 14
- Solid wire (max): 2.5 mm²
- Flexible wire (max): 1.5 mm²
- Wire with plastic collar ferrule (max): 1.5 mm²
- Wire end ferrule (max): 1.5 mm²
- Rated current (min. no. of poles, Tu=20°C): 27 A
- Rated current (min. no. of poles, Tu=40°C): 24 A
- Rated voltage for surge voltage class (pollution degree II/2): 400 V
- Rated voltage for surge voltage class (pollution degree III/3): 250 V
- Rated impulse voltage for surge voltage class (pollution degree III/2): 4 kV
- Short-time withstand current resistance: 3 x 1s with 100 A
- Rated voltage (usegroup B): 300 V
- Rated current (usegroup B): 15 A
- Wire cross-section AWG (usegroup B, min): AWG 26
- Rated voltage (usegroup D): 300 V
- Rated current (usegroup D): 15 A
- Wire cross-section AWG (usegroup D, max): AWG 14
- Rated voltage (usegroup B, UL 1059): 300 V
- Rated current (usegroup B, UL 1059): 17 A
- Certificate No. (cURus): E60693
