WEIDMULLER 1769760000 PCB Terminal Block
The Weidmueller LM series LM3R 5.08/48/90 component is a high-quality PCB terminal designed for reliable connections in electrical systems. It features a 5.08 mm pitch with 48 poles and a solder pin length of 3.5 mm, suitable for conductor cross-sections up to 2.5 mm². Constructed with tinned copper alloy contact surfaces and orange insulators, it provides excellent durability, insulation, and corrosion resistance. Ideal for various industrial wiring applications, it ensures secure, stable, and easy-to-maintain connections, complying with IEC, UL, CSA standards, and rated up to 630V/17.5A, making it suitable for automation, control panels, and instrumentation systems.
WEIDMULLER 1769760000 PCB Terminal Block Specifications:
- Pitch: 5.08 mm (0.2 inch)
- Number of poles: 48
- Solder pin length: 3.5 mm
- Dimensions: Width 84.82 mm, Height 40.1 mm, Depth 31.8 mm
- Material: Copper alloy contact, Insulating body in orange Wemid (PA)
- Clamping range: 0.2 mm to 2.5 mm
- Rated voltage: 630V (IEC), 300V (UL and CSA)
- Rated current: 17.5A (IEC), 15A (UL), 18A (CSA)
- Suitable conductor cross-section: AWG 24 to AWG 14, up to 2.5 mm²
- Solder eyelet hole diameter: 1.3 mm
- Operating temperature: -50°C to 120°C
- Flammability: UL 94 V0
- Insulation: Tinned copper contact, orange insulator
- Conductor outlet direction: 90°
- Mounting: THT solder connection
Buy the Buy Weidmueller LM3R 5.08/48/90 3.5SN OR BX Part Number 176971 Online
Purchase the Weidmueller LM3R 5.08/48/90 PCB terminal online today to ensure secure, durable, and efficient electrical connections. Designed for industrial automation with a 5.08 mm pitch and 48 poles, it features robust tinned copper contacts and high insulation standards. Easy to install on printed circuit boards using THT soldering method, it supports conductor cross-sections up to 2.5 mm², rated for 630V and 17.5A, making it ideal for automation, control systems, and instrumentation applications. Order now for fast delivery and reliable operation.
Buy Weidmueller LM3R 5.08/48/90 3.5SN OR BX now and experience unmatched reliability and performance in industrial wiring and control panels.
Frequently Asked Questions
Where can I buy WEIDMULLER 1769760000?
You can click on the BUY or RFQ button to purchase 1769760000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1769760000?
You can download the 1769760000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1769760000?
WEIDMULLER
