WEIDMULLER 1838440000 Industrial Power Connector
The Weidmiiller OMNIMATE Signal series BL/SL 5.08 high-temperature-resistant male header features a 3.2 mm solder pin, suitable for reflow and wave soldering. Designed for PCB connection, it has a 5.08 mm pitch, 2 poles, and black insulating material in a box packaging. The pin headers provide space for labeling and can be coded, with a tinned contact surface for reliable electrical connection. It is optimal for applications requiring safe power transmission and proven durability with high current capability up to 275A at 20°C. Ideal for automated assembly processes, this connector offers high reliability in industrial environments.
WEIDMULLER 1838440000 Industrial Power Connector Specifications:
- Dimensions: Width 19.96 mm, Height 15.2 mm, Depth 8.5 mm, Weight 2.26 g
- Material: Insulating LCP GF, Contact material: Tinned CuMg
- Electrical ratings: IEC 400V 275A, UL 300V/18.5A, CSA 300V/18.5A
- Pin dimensions: 1.2 mm octagonal, solder pin length 3.2 mm with tolerance ±0.3 mm
- Solder eyelet hole diameter: 1.5 mm ±0.1 mm, Pitch: 5.08 mm (0.2 inch), Number of poles: 2
- Operating temperature: -50°C to 100°C, Storage: -40°C to 70°C, Flammability: UL 94 V-0
- Number of plugging cycles: 25, Contact surface: Tinned, Connection type: PCB solder, Mounting: THT/THR
Buy the Weidmiiller Series BL/SL 5.08 Signal Male Header: 1838440000
Purchase the Weidmiiller Series BL/SL 5.08 high-temperature male header online today. Crafted for reliable PCB connections, it offers a 5.08 mm pitch, 2 poles, and a 3.2 mm solder pin, perfect for automatic assembly with reflow and wave soldering techniques. Its durable, tinned contact surfaces support high current loads up to 275A, ensuring longevity and safety in industrial applications. The black insulating housing facilitates easy identification, and the design supports up to 25 plugging cycles for dependable, repeated use. Order now and enhance your manufacturing efficiency with a proven high-quality connector.
Order your Weidmiiller Series BL/SL 5.08 1838440000 today and give your industrial projects the dependable power connection they need.
