WEIDMULLER 1844030000 Female Plug Connector

WEIDMULLER 1844030000 Female Plug Connector Specifications:

• Type: BLT 5.08HC/06/180F SN OR BX
• Order No.: 1844030000
• Version: PCB plug-in connector, female plug, 5.08 mm pitch, No. of poles: 6, 180°, TOP connection, Clamping range, max. : 2.5 mm², Box
• GTIN(EAN): 4032248355952
• Quantity: 42pc(s).
• Product data (IEC): 400 V / 27 A / 0.2 - 2.5 mm²
• Product data (UL): 300 V/17 A/AWG 26 - AWG 14
• Packaging: Box
• Net weight: 19.24 g
• Product family: OMNIMATE Signal - series
• Wire connection method: TOP connection
• Pitch in inches: 0.2 inch
• No. of poles: 6
• L1 in inches: 1 inch
• Pin series quantity: 1
• Touch-safe protection: Safe from finger touch
• Tightening torque for screw flange (min): 0.15 Nm
• Tightening torque (min): 0.4 Nm
• Clampingscrew: M 2.5
• Screwdriver blade standard: DIN 5264
• Push-in force/pole: 10 N
• Type of connection: TOP connection
• Pitch in mm: 5.08 mm
• Conductor outlet direction: 180°
• L1 in mm: 25.4 mm
• Number of rows: 1
• Rated cross-section: 2.5 mm²
• Volume resistance: 4.50 mΩ
• Stripping length: 13 mm
• Tightening torque for screw flange (max): 0.2 Nm
• Tightening torque (max): 0.5 Nm
• Screwdriver blade: 0.6 x 3.5
• Plugging cycles: 25
• Withdrawal force per pole: 8 N
• Insulating material: PBT
• Colour: Orange
• Insulating material group: IIIa
• Insulation resistance: ≥ 108Ω
• Contact material: CuSn
• Layer structure of plug contact: 4-8µm Sn hot-diptinned
• Storage temperature (min): -25 °C
• Max. relative humidity during storage: 80 %
• Operating temperature (max): 100 °C
• Temperature range (installation, max): 100 °C
• Clamping range (min): 0.13 mm²
• Wire connection cross section AWG (min): AWG 28
• Solid wire (min) H05(07)V-U: 0.2 mm²
• Flexible wire (min) H05(07)V-K: 0.2 mm²
• Wire with plastic collar ferrule (min): 0.2 mm²
• Wire with wire end ferrule (min): 0.2 mm²
• Plug gauge (EN 60999 a x b; Ø): 2.4 mm x 1.5 mm
• Clamping range (max): 2.5 mm²
• Wire connection cross section AWG (max): AWG 14
• Solid wire (max) H05(07)V-U: 2.5 mm²
• Flexible wire (max) H05(07)V-K: 1.5 mm²
• Rated current (min. no. of poles, Tu=20°C): 27 A
• Rated current (min. no. of poles, Tu=40°C): 24 A
• Rated voltage for surge voltage (pollution degree II/2): 400 V
• Rated voltage for surge voltage (pollution degree III/3): 250 V
• Rated impulse voltage for surge voltage (pollution degree III/2): 4 kV
• Short-time withstand current resistance: 3 x 1s with 100 A
• Rated voltage (usegroup B): 300 V
• Rated current (usegroup B): 15 A
• Wire cross-section AWG (usegroup B, min): AWG 26
• Rated voltage (usegroup D): 300 V
• Rated current (usegroup D): 15 A
• Wire cross-section AWG (usegroup D, max): AWG 14
• ETIM 3.0: EC001284
• ETIM 5.0: EC002637
• UNSPSC: 30-21-18-10
• eClass 6.2: 27-26-07-04
• eClass 8.1: 27-44-04-02
• eClass 9.1: 27-44-04-02
