WEIDMULLER 1929980000 Female Header Connector

WEIDMULLER 1929980000 Female Header Connector Specifications:

• Type: BVZ 7.62HP/07/180 SN BK BX
• Order No.: 1929980000
• Version: PCB plug-in connector, female plug, 7.62 mm, No. of poles: 7, 180°, Clamping yoke connection, Clamping range, max. : 10 mm², Box
• GTIN(EAN): 4032248579761
• Qty.: 50pc(s).
• Product data (IEC): 1000 V / 57 A / 0.2 - 10 mm²
• Product data (UL): 600 V/40.5 A/AWG 24 - AWG 8
• Packaging: Box
• Net weight: 37.44 g
• Product family: OMNIMATE Power - series BV/SV 7.62HP
• Wire connection method: Clamping yoke connection
• Pitch in inches(P): 0.3 inch
• No. of poles: 7
• L1 in inches: 1.8 inch
• Pin seriesquantity: 1
• Touch-safe protection acc. to DIN VDE: 0470
• Safe from finger touch: Yes
• Volume resistance: 4.50 mΩ
• Strippinglength: 12 mm
• Tighteningtorque,max.: 0.6 Nm
• Screwdriver blade: 0.6 x 3.5
• push-in force/pole: 12 N
• Type of connection: Screw connection
• Pitch in mm(P): 7.62 mm
• Conductor outlet direction: 180°
• L1 in mm: 45.72 mm
• Number of rows: 1
• Rated cross-section: 6 mm²
• IP rating: IP 20
• Coding: Yes
• Tighteningtorque,min.: 0.5 Nm
• Clampingscrew: M 3
• Pluggingcycles: 25
• Withdrawal forceperpole: 7 N
• Insulatingmaterial: PA GF
• Colour chart(similar): RAL 9011
• CTI: ≥ 500
• UL 94 flammabilityrating: V-0
• Contact material: Copper alloy
• Layer structure ofplugcontact: 6-8µm Snglossy
• Storage temperature,max.: 55 °C
• Operatingtemperature,min.: -50 °C
• Temperature range, installation, min.: -25 °C
• Colour: Black
• Insulatingmaterialgroup: II
• Insulation resistance: ≥ 108Ω
• Contact base material: Copper alloy
• Contact surface: tinned
• Storage temperature,min.: -25 °C
• Max. relative humidityduringstorage: 80 %
• Operatingtemperature,max.: 125 °C
• Temperature range, installation, max.: 100 °C
• Clampingrange,min.: 0.2 mm²
• Wire connection cross section AWG,min.: AWG 24
• Solid,min. H05(07)V-U: 0.2 mm²
• Flexible,min. H05(07)V-K: 0.5 mm²
• w. plastic collar ferrule, DIN 46228 pt 4,min.: 0.25 mm²
• w. wire end ferrule, DIN 46228 pt 1, min: 0.25 mm²
• Plug gauge acc. to EN 60999 a x b; Ø: 2.8 mm x 2.0 mm; 2.4 mm
• Clampingrange,max.: 10 mm²
• Wire connection cross section AWG,max.: AWG 8
• Solid,max. H05(07)V-U: 6 mm²
• Flexible,max. H05(07)V-K: 10 mm²
• w. plastic collar ferrule, DIN 46228 pt 4,max.: 6 mm²
• w. wire end ferrule, DIN 46228 pt 1,max.: 6 mm²
• Rated current, min. no. of poles (Tu=40°C): 41 A
• Rated voltage for surge voltage class / pollution degree III/2: 1,000 V
• Rated impulse voltage for surge voltage class/ pollution degree II/2: 6 kV
• Rated impulse voltage for surge voltage class/contamination degree III/3: 8 kV
• Clearance, min.: 10.2 mm
• Rated voltage for surge voltage class / pollution degree II/2: 1,000 V
• Rated voltage for surge voltage class / pollution degree III/3: 800 V
• Short-time withstand current resistance: 3 x 1s with 420 A
• Creepage distance, min.: 13.8 mm
• Rated voltage(UsegroupB): 600 V
• Rated voltage(usegroupC): 600 V
• Rated voltage(usegroupD): 600 V
• Rated current(usegroupB): 40.5 A
• Rated current(usegroupC): 40.5 A
• Rated current(usegroupD): 5 A
