WEIDMULLER 1940780000 PCB Plug-in Connector
The Weidmuller OMNIMATE Signal BC/SC 3.81 BCZ 3.81/07/180 SN OR BX is a versatile PCB plug-in connector designed for reliable and efficient wire connections. Featuring a 3.81mm pitch and a 180° wire outlet direction, it provides flexible connection-level design options. The clamping yoke connection ensures secure wire termination, while the compatibility with standard connector layouts simplifies integration into existing systems. This connector is suitable for a wide range of industrial applications requiring robust and space-saving connectivity solutions.
WEIDMULLER 1940780000 PCB Plug-in Connector Specifications:
- Base Material: PA GF
- Color: Orange
- Pitch (P) in inches: 0.15 inch
- Number of Poles: 7
- Wire Connection Method: Clamping yoke connection
- Clamping Range Min: 0.08 mm²
- Clamping Range Max: 1.5 mm²
- Solid Wire Min H05(07)V-U: 0.2 mm²
- Flexible Wire Min H05(07)V-K: 0.2 mm²
- Wire End Ferrule Min: 0.2 mm²
- Stripping Length: 7 mm
- Tightening Torque Max: 0.25 Nm
- Screwdriver Blade: 0.4 x 2.5
- Plugging Cycles: 25
- Rated Current (Tu=20°C): 17.5 A
- Rated Current (Tu=40°C): 15.2 A
- Rated Voltage (pollution degree III/2): 160 V
- Rated Impulse Voltage (pollution degree III/3): 2.5 kV
- Short-Time Withstand Current: 76 A
- Rated Voltage (Usegroup B - CSA): 300 V
- Rated Current (Usegroup B - CSA): 8 A
- Rated Voltage (Usegroup B - cURus): 300 V
- Rated Current (Usegroup B - cURus): 10 A
- UL 94 Flammability Rating: V-0
- Insulation Resistance: ≥ 108Ω
- Layer Structure of Plug Contact: 0.5-1.5µm Cu/2-5µm Sn
- Storage Temperature Min: -25 °C
- Storage Temperature Max: 55 °C
- Operating Temperature Min: -50 °C
- Operating Temperature Max: 120 °C
- Installation Temperature Max: 120 °C
- Volume Resistance: 6.00 mΩ
- Touch-Safe Protection (DIN VDE 57 106): Safe from finger touch
- Touch-Safe Protection (DIN VDE 0470): IP 20
- Can be Coded: Yes
- Tightening Torque Min: 0.2 Nm
- Clampingscrew: M 2
- Screwdriver Blade Standard: DIN 5264
- Push-in Force/Pole: 0 N
