WEIDMULLER 1969130000 Industrial Connector
The Weidmiiller BCF 3.81/06/180 SN OR BX is a compact, PCB plug-in connector designed for reliable wire connection in control systems. Featuring a 3.81 mm pitch and push-in connection technology, it simplifies wiring with tool-free locking and release via integrated push buttons, ensuring intuitive handling. Suitable for industrial automation, it supports 6 poles, operates efficiently within a temperature range of -60°C to 120°C, and conforms to IEC and UL standards. The orange insulating material provides high visibility, making it ideal for densely packed electrical assemblies.
WEIDMULLER 1969130000 Industrial Connector Specifications:
- Pitch: 3.81 mm (0.15 inch)
- Number of Poles: 6
- Rated Voltage: IEC 320 V, UL 300 V, CSA 300 V
- Rated Current: IEC 17.5A, UL 10A, CSA 1A
- Wire Range: AWG 26 - AWG 16 (min 0.14 mm?, max 1.5 mm?)
- Clamping Range: 0.14 mm? to 1.5 mm?
- Insulation Material: PA 66 GF 30, orange
- Flammability Rating: UL 94 V-0
- Temperature Range: -60°C to 120°C
- Contact Resistance: Volume resistance 6.00 mΩ
- Creepage & Clearance: Designed per standards for safety
- Certification: IEC, UL, CSA compliant
- Push-in Connection: Tool-free, ergonomic handling, 25 plugging cycles
Buy the Buy Weidmiiller Connector Part Number 1969130000 Online
Order the Weidmiiller industrial connector with push-in technology today for fast, secure wiring in automation applications. Its compact design, easy handling, and excellent electrical ratings make it perfect for dense control panels. This high-quality connector is suitable for wire sizes AWG 26 to AWG 16, supports numerous plug-in cycles, and complies with IEC, UL, and CSA standards. Get this reliable, easy-to-use connector for your automation projects and streamline your wiring processes effectively.
Buy Weidmiiller Part Number 1969130000 now and experience unmatched reliability and efficient wiring for industrial automation and control systems.
Frequently Asked Questions
Where can I buy WEIDMULLER 1969130000?
You can click on the BUY or RFQ button to purchase 1969130000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1969130000?
You can download the 1969130000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1969130000?
WEIDMULLER
