WEIDMULLER 1970400000 PCB connector
The Weidmüller BCF 3.81/06/180F SN OR BX is a PCB plug-in connector with a 3.81 mm pitch, designed for easy, tool-free wire connection using push-in technology. It features 6 poles, a 180° outlet direction, and a compact form suitable for space-saving applications, offering reliable electrical contact with a rated voltage of 300V and current of 10A. Constructed with orange PA GF insulation, it provides high dielectric strength and fire safety, meeting UL V-0 standards. Its modular design supports up to 25 push-in cycles for durable performance in electrical systems, making it ideal for industrial automation and control panels.
WEIDMULLER 1970400000 PCB connector Specifications:
- Pitch: 3.81 mm (0.15 inch)
- Poles: 6
- Outlet direction: 180°
- Rated Voltage: 300V
- Rated Current: 10A
- Wire cross-section: AWG 26 - AWG 16
- Clamping range: 0.14 - 1.5 mm²
- Insulating material: PA GF, orange, UL V-0 rated
- Flammability rating: V-0
- Contact Material: Tin-plated phosphor bronze
- Storage temperature: -25°C to 55°C
- Operating temperature: -60°C to 120°C
- Certification: UL, CSA
- Number of push-in cycles: 25
Buy the Weidmueller Series BC/SC 3.81: PCB Plug-in Connector 1970400000
Purchase the Weidmueller PCB connector with push-in technology, 6 poles, 3.81 mm pitch, rated at 300V and 10A. Designed for easy, tool-free wiring, it features reliable contact and high insulation safety. Its compact size makes it suitable for densely populated control panels and automation systems, ensuring efficient space utilization. Made with flame-retardant orange PA GF, it complies with UL V-0 standards, offering durability, safety, and ease of installation. Perfect for industrial wiring where reliable connectivity and space efficiency are essential.
Get Weidmueller PCB connector 1970400000 today—built for precision, space-saving wiring, and long-lasting durability in industrial environments.
Frequently Asked Questions
Where can I buy WEIDMULLER 1970400000?
You can click on the BUY or RFQ button to purchase 1970400000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1970400000?
You can download the 1970400000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1970400000?
WEIDMULLER
