WEIDMULLER 1970440000 Push-in PCB connector
The Weidmueller BCF 3.81/07/180F SN OR BX is a compact, high-density PCB connector designed for quick and tool-free wire connections with push-in technology. Its 3.81 mm pitch and 7 poles facilitate reliable, space-saving electronic assembly in industrial automation and control systems. Featuring a robust orange PA GF insulating body, it supports flexible and solid wires from 0.14 mm² to 1.5 mm², with a max uptime of 25 push-in cycles. Certified for various standards, it ensures safety, durability, and easy installation in demanding environments.
WEIDMULLER 1970440000 Push-in PCB connector Specifications:
- Pitch: 3.81 mm (0.15 inch)
- Number of poles: 7
- Rated voltage: 320 V (IEC), 300 V (UL/CSA)
- Rated current: 17.5 A (IEC), 10 A (UL/CSA)
- Wire cross-section: 0.14 mm² to 1.5 mm² (AWG 26 to AWG 16)
- Insulating material: Polyamide GF Orange
- Flammability rating: UL 94V-0
- Operating temperature: -60°C to +120°C
- Contact resistance: ≤ 6 mΩ
- Number of insertion cycles: 25
- Protection class: IP20
- Certifications: UL, CSA, RoHS
Buy the Buy Weidmueller BCF 3.81/07/180F SN OR BX Part Number 1970440000 Online
Get your Weidmueller BCF 3.81/07/180F SN OR BX connector today for fast, tool-free wire assembly that ensures secure and reliable connections in your equipment. Its compact design and high current capacity make it ideal for space-critical automation applications. Easy to install and maintain, this connector supports a wide range of wire sizes from 0.14 mm² to 1.5 mm², offering excellent flexibility. Trust Weidmueller’s quality for safe, durable, and efficient electrical connections in industrial environments.
Buy Weidmueller BCF 3.81/07/180F SN OR BX now and experience unmatched reliability and space-efficient wire connection for industrial automation tasks.
Frequently Asked Questions
Where can I buy WEIDMULLER 1970440000?
You can click on the BUY or RFQ button to purchase 1970440000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1970440000?
You can download the 1970440000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1970440000?
WEIDMULLER
