WEIDMULLER 1971020000 Signal Connector
The SCZ 3.81/12/180F SN OR BX is an inverted pin plug designed for 3.81-mm pitch wire-to-wire connections. Suitable for PCB mating or wire pairing, it features clamping-yoke screw connection, space for labelling, and coding options. Available in various flange configurations, it supports conductor sizes from 0.08 mm² to 1.5 mm², with a rated voltage of 320V and current of 17.5A. Its durable design and compliance with safety standards make it ideal for industrial and automation applications. The connector ensures secure, reliable connections for signal and power transfer in complex systems.
WEIDMULLER 1971020000 Signal Connector Specifications:
- Pitch in mm: 3.81 mm
- Number of poles: 12
- Rated voltage: 320 V (IEC), 300 V (UL & CSA)
- Rated current: 17.5 A (IEC), 10 A (UL & CSA)
- Conductor cross-section: 0.08 mm² to 1.5 mm² (AWG 28 to AWG 16)
- Flammability rating: UL 94 V-0
- Insulation material: PA GF (Orange)
- Temperature range, operating: -60°C to 120°C
- Protection class: IP20
- Tightening torque: 0.2 Nm to 0.3 Nm
- Screwdriver size: 0.4 x 2.5 mm
- Number of rows: 1
- Dimensions: Length approximately 41.91 mm, width varies with configuration
- Locking options: Without flange, with flange, with inverted flange, with release latch
Buy the Weidmueller 1971020000 – Reliable Signal Connector for Industrial Applications
Purchase the Weidmueller Signal Connector today for secure, reliable wire-to-wire and PCB connections. Crafted with high-quality materials, it supports a broad range of conductor sizes, ensures safety through UL and IEC standards, and features easy assembly with screw or latch options. Its compact design and IP20 protection make it suitable for industrial environments. Whether for automation, control panels, or signal transfer in complex systems, this connector delivers superior performance, durability, and easy installation—order now and enhance your system’s reliability.
Get Weidmueller 1971020000 today—built for precision and long-lasting durability in industrial wiring and automation systems.
