WEIDMULLER 1972220000 4-Pole PCB Connector
The Weidmueller BCF 3.81/04/180LR is a compact, PCB plug-in connector suitable for electrical and automation projects. It features 4 poles with a pitch of 3.81 mm (0.15 inch) and utilizes a push-in wire connection method for easy, tool-free assembly. The connector is rated for 17.5A at 320V and is suitable for solid or flexible conductors from AWG 26 to AWG 16. Its robust insulating material is orange in color, with a flame rating of UL 94V-0, ensuring safety and reliability in diverse industrial environments. The connector supports up to 25 push-in cycles, making it suitable for secure and repeated connections.
WEIDMULLER 1972220000 4-Pole PCB Connector Specifications:
- Number of poles: 4
- Pitch: 3.81 mm (0.15 inch)
- Rated voltage: 320 V
- Rated current: 17.5 A
- Clamping range: 0.14 mm² to 1.5 mm² (AWG 26-16)
- Insulating material: PA GF, orange, UL 94V-0
- Number of connection cycles: 25
- Operating temperature: -25°C to 55°C
- Storage temperature: -25°C to 55°C
- Protection class: IP 20
- Wire outlet direction: 180°
- Dimensions: not specified
- Certifications: UL, CSA, RoHS compliant
Buy the Buy Weidmueller PCB Connector Part Number 1972220000 Online
Purchase your Weidmueller PCB connector with 4 poles today online for reliable, tool-free wiring in automation projects. Featuring push-in connection, rated for 17.5A at 320V, with a pitch of 3.81 mm, it simplifies assembly and ensures secure connections. The connector supports a wide range of conductor sizes from AWG 26 to AWG 16, suitable for both solid and flexible conductors. Its durable orange insulator complies with UL 94V-0, providing safety and high packaging density, perfect for industrial environments. Get yours now!
Order your Weidmueller Series BC/SC 3.81 connector with 4 poles today and enjoy easy, reliable wiring solutions for industrial automation and control systems.
Frequently Asked Questions
Where can I buy WEIDMULLER 1972220000?
You can click on the BUY or RFQ button to purchase 1972220000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1972220000?
You can download the 1972220000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1972220000?
WEIDMULLER
