WEIDMULLER 7760056069 Industrial Automation Relay
The Weidmueller DRM270024LT is a compact relay featuring 2 CO contacts, designed for industrial automation. It offers a wide range of coil voltages including 24 V DC, with a control current of 37.8 mA and a rated control voltage of 24 V DC. This relay supports a continuous current of 10 A and has optional features like a test button, integrated status LED, and freewheel diode. Its small size measures 21mm in width and 27.4mm in height, making it suitable for panel mounting and automation control systems, with robust insulation and compliance with safety standards.
WEIDMULLER 7760056069 Industrial Automation Relay Specifications:
- Width: 21 mm (0.827 inch)
- Height: 27.4 mm (1.079 inch)
- Depth: 35.7 mm (1.406 inch)
- Weight: 35.99 g
- Rated control voltage: 24 V DC
- Control current: 37.8 mA
- Power rating: 0.9 W
- Rated switching voltage: 250 VAC
- Max switching voltage: 250 V AC
- Continuous current: 10 A
- Inrush current: 20 A/50 ms
- AC switching capacity: 2500 VA
- DC switching capacity: 240 W @ 24 V
- Switch-on/off delay: <20 ms
- Contact resistance: <50 mΩ
- Mechanical life: 20 million cycles
- Protection degree: IP20
- Dielectric strength: input-output 1 kV/1 min, contact open contact 1.8 kV/1 min
- Impulse withstand voltage: 6 kV (1.2/50 us)
- Environmental conditions: -40°C to 60°C, humidity 35-85%, no condensation
- Standards: IEC 61810-1, UL 508, EN certifications
- Connection method: Plug-in
- Approvals: RoHS compliant
Buy the Weidmueller DRM270024LT – Reliable Relay for Industrial Applications
Order the Weidmueller DRM270024LT relay online today for your automation setup. With 2 CO contacts, 24 V DC control, and a robust 10 A capacity, this relay is ideal for controlling industrial circuits. Its compact design (21mm wide) fits easily into control panels, offering high reliability, fast switching (<20 ms delay), and optional features like a test button and LED status indicator. Perfect for automation engineers looking for durable, standards-compliant relays for demanding environments.
Get Weidmueller DRM270024LT today—built for precision, durability, and industrial automation reliability.
Frequently Asked Questions
Where can I buy WEIDMULLER 7760056069?
You can click on the BUY or RFQ button to purchase 7760056069 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 7760056069?
You can download the 7760056069 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 7760056069?
WEIDMULLER
