WEIDMULLER 1972830000 PCB Header
This two-tier PCB header from the OMNIMATE Signal series offers reliable connections with a 3.81mm pitch, suitable for wave soldering applications. It features 12 poles with a 90° outlet direction and a solder pin length of 3.2mm, designed for easy access and space for labeling. Made from orange insulating PA GF with tinned copper alloy contacts, it supports rated currents up to 17.5A and voltage up to 320V. Its robust construction ensures durability in industrial environments, with certifications including UL and IEC compliance, providing a versatile solution for electronic and electrical assembly needs.
WEIDMULLER 1972830000 PCB Header Specifications:
- Pitch: 3.81 mm (0.15 inch)
- Number of poles: 12
- Solder pin length: 3.2 mm ±0.02 mm
- Pin diameter: 1.0 mm, octagonal, tolerance 0/-0.03 mm
- Solder eyelet hole diameter: 1.2 mm ±0.1 mm
- Material: PA GF orange, contact material: Copper alloy, tinned
- Operating temperature: -50°C to 120°C
- Rated current: 17.5A at 20°C, 13.9A at 40°C
- Rated voltage: 320V (IEC), 300V (UL/CSA)
- Flammability rating: UL 94V-0
- Insulation resistance: >10² MΩ
- Touch-safe protection: yes, DIN VDE compliant
- Plugging cycles: 25
- Color: Orange (similar to RAL 2000)
Buy the Weidmueller 1972830000 – Reliable PCB Header for Industrial Applications
Experience reliable electrical connectivity with the Weidmueller PCB header designed for industrial applications. Featuring 12 poles with a 3.81mm pitch and a 90° outlet direction, it ensures optimal space utilization and ease of assembly. Constructed from durable orange PA GF with tinned copper contacts, it supports up to 17.5A and 320V, meeting UL and IEC standards. Its robust design and easy-to-use features make it ideal for automation, control panels, and electronic devices, ensuring long-lasting performance in demanding conditions.
Get Weidmueller 1972830000 today—built for precision, durability, and reliable electrical connections in industrial environments.
