WEIDMULLER 1080320000 Industrial Power and Signal Connector
The BVF 7.62HP/02/180 BCF/OG6R SN BK BX is a versatile 2-pole female plug from the OMNIMATE Power series, designed for power and signal connections in industrial applications. Featuring PUSH IN connection technology and a self-locking middle flange, it supports simultaneous connection of power, signals, and optional shielding. Meets IEC and UL standards for voltage and current ratings, with a compact design reducing space requirements. Suitable for connecting servo and asynchronous drives with high reliability. The product ensures secure connections with its pluggable shield option and robust copper contact surfaces.
WEIDMULLER 1080320000 Industrial Power and Signal Connector Specifications:
- Type: PCB plugin connector, female plug, 2 poles, 180°, PUSH IN
- Pitch: 7.62 mm (0.3 inch)
- Number of rows: 1
- Rated voltage: 600V (IEC, UL)
- Rated current: 35A (IEC, UL)
- Clamping range: 0.5 mm² to 10 mm²
- Wire connection: PUSH IN
- Material: Copper alloy contacts, tinned surface
- Insulation: PA GF, black, UL V0
- Temperatures: -25°C to 125°C operating, -60°C to 55°C storage
- Ingress Protection: IP20
- Creepage & Clearance: ≥10.4mm & ≥12.7mm
- Stripping length: 8-12 mm
- Number of poles: 2
- Plugging cycles: 25
- Standards: IEC 61800-5-1, UL 1059 class C 600V
- Dimensions: Based on 7.62 mm pitch, compact design suitable for industrial environments
Buy the Buy Weidmueller BVF 7.62HP/02/180 BCF/OG6R SN BK BX Online
Purchase the Weidmueller BVF 7.62HP/02/180 BCF/OG6R SN BK BX online to ensure secure, high-quality power and signal connections in industrial automation. Its PUSH IN technology allows quick, tool-free wiring, reducing installation time. The connector's compact design supports efficient space utilization while meeting IEC and UL standards for voltage and current ratings. Ideal for connecting servo and asynchronous drives, it features robust copper contacts, a tinned surface for corrosion resistance, and an IP20 rating for protection against dust. Reliable and durable, this connector simplifies wiring and enhances system safety in demanding industrial environments.
Buy Weidmueller BVF 7.62HP/02/180 BCF/OG6R SN BK BX now and experience reliable, secure power and signal connections for industrial drive systems.
