WEIDMULLER 1985800000 Spring Connection Terminal Block
The WEIDMULLER ZQV 1.5N/10 RD is a spring connection terminal block designed with innovative PUSH IN technology. This technology minimizes wiring time and ensures high conductor pull-out forces. Constructed from Wemid material with a V-0 flammability rating, it offers robust performance and safety. The block is suitable for a wide range of industrial applications requiring efficient and reliable connections, such as power distribution, automation, and control systems. Its plugged fixing type and 3.5mm pitch make it versatile for various panel configurations.
WEIDMULLER 1985800000 Spring Connection Terminal Block Specifications:
- Order No.: 1985800000
- GTIN(EAN): 4050118370393
- Quantity: 20 pc(s).
- Width: 33.5 mm
- Width(inches): 1.319 inch
- Height: 21.9 mm
- Height(inches): 0.862 inch
- Depth: 2.8 mm
- Depth(inches): 0.11 inch
- Net weight: 3.391 g
- Material: Wemid
- UL 94 flammability rating: V-0
- Colour: Red
- Explosion-tested version: Yes
- Type of fixing: Plugged
- Pitch in mm (P): 3.5 mm
- Rated current: 17.5 A
- ETIM 6.0: EC000489
- eClass 9.1: 27-14-11-40
- eClass 6.2: 27-14-11-40
Buy the 1985800000 WEIDMULLER Spring Connection Terminal Block | myMectronic
Purchase the WEIDMULLER 1985800000 ZQV 1.5N/10 RD terminal block securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy WEIDMULLER 1985800000?
You can click on the BUY or RFQ button to purchase 1985800000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1985800000?
You can download the 1985800000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1985800000?
WEIDMULLER
