WEIDMULLER 2439650000 PCB Push-In Connector
The Weidmiiller OMNIMATE Signal series BL/SL 2.50 features a PCB plug-in connector with push-in direct insertion, 3 poles, and a pitch of 2.5 mm. Designed for easy wire connection, it supports a wide range of conductor sizes, including AWG 28-20. The connector has an insulating material made of black PA with a touch-safe design aligned with DIN VDE standards. Suitable for use in industrial control panels, it provides reliable electrical connections with rated current of 6A and operates within a temperature range of -40°C to 105°C, making it ideal for automation and control applications.
WEIDMULLER 2439650000 PCB Push-In Connector Specifications:
- Pitch: 2.5 mm (0.984 inch)
- Number of Poles: 3
- Material: PA (Polyamide), black with tin-plated copper contacts
- Rated Current: 6A at 20°C
- Rated Voltage: 320 V (IEC), 150 V (UL/CSA)
- Clamping Range: 0.08-0.5 mm² (AWG 28-20)
- Conductor types: solid, stranded, flexible, wire end ferrules
- Operating Temperature: -40°C to 105°C
- Touch-safe protection according to DIN VDE
- Certifications: IEC 320 V/6 A, UL 150 V/5 A, CSA 150 V/5 A
- Number of connection cycles: 25
- Flammability Rating: UL 94 V-0
- Connection Method: Push-in direct insertion
- Protection Class: IP20
Buy the Weidmiiller Series BL/SL 2.50 PCB Connector: 2439650000
Discover the efficient and reliable PCB push-in connector from Weidmiiller, designed for quick and secure wiring in industrial automation. With a 2.5 mm pitch and 3 poles, it provides a robust electrical connection suitable for various conductor types including AWG 28-20. It features a user-friendly push-in process, a safe touch-proof design per DIN VDE standards, and operates at temperatures from -40°C to 105°C. Ideal for control cabinets, motor starters, and automation systems, order online today and enhance your project’s wiring efficiency and safety.
Buy Weidmiiller Series BL/SL 2.50 connector now and experience reliable, quick wiring solutions for industrial control panels and automation systems.
